System And Components
Assembly
100%

161-0125 LINES GP-GAS (CHG -00, -01, -01D1)LOW BTU

Group No: 161-0125
Part NumberPart NameQty
0S15881 BOLT (3/8-16X1.25-IN)32
0S15902 BOLT (3/8-16X2-IN)6
0S15913 BOLT (3/8-16X1.5-IN)15
0S15944 BOLT (3/8-16X1-IN)6
3V33085 WASHER-HARD (10.2X20.5X2.5-MM THK)44
5P82116 SEAL-O-RING8
6I23947 TUBE AS8
6I26598 TUBE AS1
6J22449 SEAL-O-RING16
6V503910 CLIP (SLOT)3
6V504011 CLIP (TAB)3
6V504912 SEAL-O-RING18
6V800213 SEAL-O-RING1
6V863614 CONNECTOR8
7E821715 TUBE AS8
8C686816 CONNECTOR16
8L277917 SEAL-O-RING32
8M714518 WASHER (10.2X28.5X5-MM THK)6
8M902419 WASHER-HARD (10.2X22.5X5-MM THK)12
8T007520 CONNECTOR8
9D619621 CLIP (SLOT)3
9D619722 CLIP (TAB)3
9L913223 WASHER-HARD (10.2X25.5X2.5-MM THK)10
9S419124 PLUG (9/16-18-THD)2
9S875225 NUT-FULL (3/8-16-THD)12
105404626 TUBE AS8
110835827 VALVE-NEEDLE8
124963328 CLIP (SLOT)1
129079629 BRACKET AS3
129079730 BRACKET AS3
159204631 ADAPTER AS1
