System And Components
100-6855 BOX GP-JUNCTION (CHG -00)PART OF 101-1271 SCHEMATIC & COMPONENT GP
Group No: 100-6855
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E0357 | 1 DIODE AS | 1 | |
| 9S8752 | 2 NUT-FULL (3/8-16-THD) | 4 | |
| 4P0311 | 3 PANEL AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 2 | |
| 3V3308 | 4 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 3E0355 | 5 BLOCK-FUSE | 1 | |
| 9X9614 | 6 TERMINAL (SINGLE) | 20 | |
| 9X9615 | 7 TERMINAL (SINGLE) | 60 | |
| 9X9676 | 8 TERMINAL | 166 | |
| 3L3866 | 9 SCREW-MACHINE (6-32X0.5-IN) | 20 | |
| 9X9677 | 10 COVER-END | 2 | |
| 9X2077 | 11 COVER | ||
| 3E8542 | 12 CONTROL GP-ENGINE MONITORING (TEMPERATURE PRESSURE MODULE) | 1 | |
| 1B2714 | 13 BOLT (1/4-20X2.5-IN) | 2 | |
| 5P0537 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 3N5714 | 15 RELAY AS (24-VOLT) | 1 | |
| 4W8787 | 16 SOCKET-RELAY | 1 | |
| 2D3077 | 17 SCREW-MACHINE (6-32X0.75-IN) | 2 | |
| 1007061 | 18 HARNESS AS | 1 | |
| 3E0105 | 19 MOUNT | 4 | |
| 8L8413 | 20 STRAP-CABLE (WHITE) | 4 | |
| 9X9675 | 21 BRACKET-END | 10 | |
| 3E5504 | 22 BAR-FIXED BRIDGE | 2 | |
| 9X9616 | 23 COVER-END | 3 | |
| 3E5503 | 24 BAR-FIXED BRIDGE | 1 | |
| 9X2603 | 25 DUCT | ||
| 3E7992 | 26 FUSE (30-AMPERE)(30 AMP) | 1 | |
| 2W8798 | 27 SWITCH AS-PUSH BUTTON | 1 | |
| 2W8683 | 28 BLOCK-CONTACT | 1 | |
| 3E6368 | 29 MODULE-RELAY | 1 | |
| 0870546 | 30 RELAY (24-VOLT) | 1 | |
| 2W6090 | 31 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 3E0356 | 32 BLOCK-TERMINAL | 1 | |
| 5N4988 | 33 DIODE AS | 1 | |
| 9X6442 | 34 SEAL | ||
| 6K2198 | 35 BOSS (3/8-16X1-IN) | 1 | |
| 7E0717 | 36 LATCH AS-DOOR | 2 |
