System And Components
129-7636 BOX GP-JUNCTION (CHG -02 THRU -04)PART OF 142-5015 WIRING GP-ENGINE
Group No: 129-7636
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E0105 | 1 MOUNT | 5 | |
| 3E0369 | 2 BRIDGE-INSERTION | 7 | |
| 3E0368 | 3 STRIP-CONTACT | 2 | |
| 4P4251 | 4 GASKET | 2 | |
| 5S4246 | 7 LOCKWASHER | 8 | |
| 6B4540 | 8 NUT (4-40-THD) | 8 | |
| 8C8560 | 9 SCREW-LOCK (4-40X0.5-IN) | 8 | |
| 8L8413 | 10 STRAP-CABLE (WHITE) | 5 | |
| 9T2968 | 11 SCREW-MACHINE (M6X1X16-MM) | 4 | |
| 9X0481 | 12 RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 1972686 | 13 BRACKET | 2 | |
| 1108714 | 14 END-WIRE (18-GA) | 10 | |
| 2092140 | 15 KIT-MARKER | 1 | |
| 2638768 | 16 COVER | 2 | |
| 2627411 | 17 BLOCK-TERMINAL (600-VOLT, 30-AMPERE) | 36 | |
| 1179564 | 18 RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 1267964 | 19 BOX AS | 1 | |
| 1267965 | 20 PLATE AS | 1 | |
| 1284461 | 26 KIT-MARKER (INCLUDES 10-TAGS)(INCLUDES 10-TAGS) | 1 | |
| 1057692 | 27 ISOLATOR | 7 | |
| 5P5677 | WIRE (18-GA, BLACK) | ||
| 1272189 | KIT-MARKER (INCLUDES 36-TAGS)(INCLUDES 36-TAGS) | 1 |
