System And Components
141-6401 BOX GP-JUNCTION (CHG -03 THRU -05)INLINE HYDRAX
Group No: 141-6401
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1615 | 1 BOLT (1/4-20X0.75-IN) | 3 | |
| 1B2714 | 2 BOLT (1/4-20X2.5-IN) | 2 | |
| 1S9593 | 3 STRAP-CABLE | 2 | |
| 2W6090 | 4 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 3E0105 | 5 MOUNT | 3 | |
| 2045569 | 6 BLOCK-TERMINAL | 7 | |
| 3E0357 | 7 DIODE AS | 1 | |
| 1748737 | 8 BAR-FIXED BRIDGE | 1 | |
| 3E3566 | 9 BRIDGE-INSERTION | 1 | |
| 3T9377 | 10 RESISTOR | 1 | |
| 3V3308 | 11 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 4P4251 | 12 GASKET | 1 | |
| 5P0537 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 5S4246 | 14 LOCKWASHER | 4 | |
| 6B4540 | 15 NUT (4-40-THD) | 4 | |
| 7G0020 | 16 RESISTOR | 2 | |
| 7S1201 | 17 SCREW-MACHINE (8-32X0.375-IN) | 33 | |
| 8C8560 | 18 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 8D9537 | 19 CAP-DUST | 1 | |
| 8T1296 | 20 WASHER (10.5X19X3.5-MM THK) | 1 | |
| 8L8413 | 21 STRAP-CABLE (WHITE) | 1 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 4 | |
| 2255522 | 23 BLOCK-TERMINAL (800-VOLT, 41-AMPERE) | 9 | |
| 2045570 | 24 COVER-END | 1 | |
| 1972686 | 25 BRACKET | 4 | |
| 9X9616 | 26 COVER-END | 1 | |
| 3E0368 | 27 STRIP-CONTACT | 6 | |
| 1972690 | 28 BLOCK-FUSE | 5 | |
| 1057692 | 29 ISOLATOR | 22 | |
| 2381271 | 30 COVER-END | 2 | |
| 2719106 | 31 COVER | 1 | |
| 1096507 | 32 SWITCH AS-PUSH BUTTON | 1 | |
| 2627411 | 33 BLOCK-TERMINAL (600-VOLT, 30-AMPERE) | 99 | |
| 2638768 | 34 COVER | 5 | |
| 1152542 | 35 PLUG | 3 | |
| 2287417 | 36 COVER | 2 | |
| 2719105 | 37 TERMINAL | 9 | |
| 1216159 | 38 MODULE-RELAY | 3 | |
| 1253903 | 39 PANEL AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 5 | |
| 1053410 | NUT-CLINCH | 33 | |
| 1220801 | 40 HARNESS AS-BOX | 1 | |
| 1S9593 | STRAP-CABLE | 9 | |
| 3S2093 | STRAP-CABLE | 5 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8T6342 | TUBE-HEAT SHRINK (3.2-MM DIA)(15-CM) | ||
| 9X6987 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(4-CM) | ||
| 1220802 | 41 BOX AS-JUNCTION | 1 | |
| 1246116 | 42 CONTROL GP-ELECTRONIC | 1 | |
| 1976949 | 43 STRIP-CONTACT | 1 | |
| 1271626 | 44 BLOCK-CONTACT | 1 | |
| 1287375 | 45 CONTROL GP-ENGINE MONITORING | 1 | |
| 1422499 | 46 HARNESS AS-WIRING | 1 | |
| 1S9593 | STRAP-CABLE | 2 | |
| 3E5412 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 3S2093 | STRAP-CABLE | 13 | |
| 8L8413 | STRAP-CABLE (WHITE) | 4 | |
| 1798907 | 47 BLOCK-TERMINAL (400-VOLT, 16-AMPERE) | 2 | |
| 3E0356 | 48 BLOCK-TERMINAL | 2 | |
| 3E0369 | 49 BRIDGE-INSERTION | 5 | |
| 3K8782 | 50 FUSE (10-AMPERE) | 5 | |
| 1416403 | 51 KIT-MARKER (INCLUDES 88-TAGS)(INCLUDES 88-TAGS) | 1 | |
| 2092143 | 52 KIT-MARKER | 1 | |
| 1253900 | 53 COVER-WIRING DUCT (187CM) | ||
| 1253900 | 54 COVER-WIRING DUCT (57CM) | ||
| 1253898 | 55 DUCT-WIRE (58-CM) | ||
| 1253898 | 56 DUCT-WIRE (186-CM) | ||
| 1253901 | 57 COVER-WIRING DUCT (66-CM) | ||
| 1253901 | 58 COVER-WIRING DUCT (26-CM) | ||
| 1253899 | 59 DUCT-WIRE (65-CM) | ||
| 1253899 | 60 DUCT-WIRE (27CM) | ||
| 1257874 | 61 TUBE-HEAT SHRINK (5.72-MM DIA)(8-CM) | ||
| 1057693 | 62 ISOLATOR | 3 |
