System And Components
3E-7305 CONTROL GP-ENGINE ELECTRONIC (CHG -05)ESS BASIC-CSA
Group No: 3E-7305
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X3018 | 1 BOX AS | 1 | |
| 5P4016 | NUT-TAB WELD (10-32-THD) | 17 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 5P4015 | NUT-TAB WELD | 4 | |
| 9X6442 | SEAL (342 CM) | ||
| 7N7792 | 2 PLUG AS-CONNECTOR (30-PIN) | 1 | |
| 2492442 | 3 CONTROL GP-ENGINE ELECTRONIC | 1 | |
| 3923180 | KIT-ENGINE CONVERSION (G3606) | 1 | |
| 3923179 | KIT-ENGINE CONVERSION (G3608) | 1 | |
| 3923178 | CONVERSION AR-ENGINE (KIT)(G3612) | 1 | |
| 3923177 | CONVERSION AR-ENGINE (KIT)(G3616) | 1 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9S8752 | 5 NUT-FULL (3/8-16-THD) | 8 | |
| 8N1525 | 6 PLUG AS-CONNECTOR (20-PIN) | 1 | |
| 8N1514 | 7 PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 3E0105 | 8 MOUNT | 2 | |
| 8L8413 | 9 STRAP-CABLE (WHITE) | 2 | |
| 6V3276 | 10 CONNECTOR AS | 1 | |
| 3E0308 | 11 DUCT-SLOTTED | 5 | |
| 3E0311 | 12 COVER | 6 | |
| 3E7992 | 13 FUSE (30-AMPERE) | 6 | |
| 3E2129 | 17 CONNECTOR AS | 1 | |
| 3E0310 | 20 DUCT-SOLID | 1 | |
| 9X9612 | 24 COVER (SPACER) | 1 | |
| 9X9674 | 25 TERMINAL | 20 | |
| 9X9613 | 26 SPACER (50-MM LGX2.5-MM THK) | 1 | |
| 9X9673 | 27 CONNECTOR (BLOCK) | 12 | |
| 1735413 | 28 CLAMP | 13 | |
| 3E2283 | 29 BRIDGE-INSERTION | 1 | |
| 3E2286 | 30 STRIP-CONTACT | 8 | |
| 3E2282 | 31 BRIDGE-INSERTION | 2 | |
| 3E2284 | 32 BRIDGE-INSERTION | 1 | |
| 9X9616 | 33 COVER-END | 4 | |
| 1069819 | 34 TERMINAL | 4 | |
| 9X9676 | 35 TERMINAL | 98 | |
| 9X9677 | 36 COVER-END | 1 | |
| 9X9615 | 37 TERMINAL (SINGLE) | 36 | |
| 3E0355 | 38 BLOCK-FUSE | 1 | |
| 0870546 | 39 RELAY (24-VOLT)(PRESSURE SWITCH) | 1 | |
| 0870546 | 39A RELAY (24-VOLT)(SLAVE) | 1 | |
| 3E3616 | 40 RELAY AS (12-VOLT)(PRELUBE) | 1 | |
| 1017685 | 41 MODULE-RELAY | 3 | |
| 4P4251 | 42 GASKET | 1 | |
| 9X6987 | 43 RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 6K3274 | 44 PLATE-RIVET | 4 | |
| 2S6251 | 45 SCREW (4-40X0.75-IN) | 4 | |
| 6B4540 | 46 NUT (4-40-THD) | 4 | |
| 2305580 | 47 SCREW-BUTTON HEAD (10-32X0.25-IN) | 23 | |
| 2W5907 | 48 WASHER (5.16X11.13X0.81-MM THK) | 23 | |
| 9X6857 | 49 SOCKET-CONNECTOR (16-GA TO 18-GA) | 54 | |
| 9G3695 | 50 PLUG-SEAL | 3 | |
| 8D9537 | 51 CAP-DUST | 1 | |
| 3E0356 | 52 BLOCK-TERMINAL | 3 | |
| 3E0357 | 53 DIODE AS | 2 | |
| 3E2246 | 54 MODULE-RELAY (24-VOLT) | 1 | |
| 1069347 | 55 HOLDER-FUSE | 1 | |
| 1069352 | 56 FUSE (1-AMPERE) | 1 | |
| 9X8551 | CABLE-ELECTRICAL (16-GA)(257-CM) | ||
| 5P5677 | WIRE (18-GA, BLACK)(34-M) | ||
| 5P5677 | WIRE (18-GA, BLACK)(35-M) | ||
| 5P5677 | WIRE (18-GA, BLACK)(0.6-M) | ||
| 5P5677 | WIRE (18-GA, BLACK)(1.2-M) | ||
| 5P5677 | WIRE (18-GA, BLACK)(0.6-M) | ||
| 5P5677 | WIRE (18-GA, BLACK)(32-M) |
