System And Components
162-7292 CONTROL GP-GAS PRESSURE (CHG -00 THRU -02)GAS HIGH PRESSURE MODULE
Group No: 162-7292
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B1237 | 1 SCREW-MACHINE (10-32X12.7-MM) | 9 | |
| 8C7507 | 2 LOCKWASHER | 6 | |
| 4B4274 | 3 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 8F1434 | 4 LOCKWASHER | 2 | |
| 4P4251 | 5 GASKET | 1 | |
| 5S4246 | 6 LOCKWASHER | 1 | |
| 6B4540 | 7 NUT (4-40-THD) | 1 | |
| 3N3691 | 8 TERMINAL | 1 | |
| 8T3993 | 9 CLAMP-HOSE | 6 | |
| 4B2041 | 10 NUT (6-32-THD) | 4 | |
| 4B5324 | 11 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 3L8187 | 12 LOCKWASHER | 4 | |
| 8T6342 | 13 TUBE-HEAT SHRINK (3.2-MM DIA)(27-CM) | ||
| 7T4577 | 14 PIN-CONNECTOR | 18 | |
| 6V2689 | 15 TUBE-HEAT SHRINK (6.35-MM DIA)(0.1-M) | ||
| 5P5623 | 16 WIRE-ELECTRICAL (16-GA, BLACK)(0.3-M) | ||
| 2L8076 | 17 TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 3 |
