System And Components
7C-0448 IGNITION GP-GAS ENGINE (CHG -00 THRU -12, -12D1, -13, -13A1-13B1 THRU -15, -15D1)VARIABLE TIMING
Group No: 7C-0448
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1590 | 1 BOLT (3/8-16X2-IN) | 4 | |
| 0S1591 | 2 BOLT (3/8-16X1.5-IN) | 5 | |
| 0S1618 | 3 BOLT (5/16-18X1-IN) | 24 | |
| 0S1621 | 4 BOLT (1/2-13X1-IN) | 2 | |
| 1H3338 | 5 LOCKWASHER | 1 | |
| 2D7134 | 6 STRAP AS | 1 | |
| 3P0650 | 7 SEAL-O-RING | 8 | |
| 3V3308 | 8 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 1455640 | 9 BOX AS-CONTROL | 1 | |
| 1084070 | HARNESS AS | 1 | |
| 5P0537 | 10 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1418951 | 12 SPARK PLUG | 8 | |
| 8T1890 | 13 CLIP (TAB) | 2 | |
| 6V1196 | 14 SEAL-O-RING | 1 | |
| 6V3830 | 15 SEAL-O-RING | 8 | |
| 7E1392 | 16 PLATE | 1 | |
| 7E1430 | 17 HARNESS AS | 1 | |
| 7E3056 | 18 HARNESS AS-WIRING (IGNITION) | 8 | |
| 7E3222 | 19 MOUNT-FLEXIBLE | 4 | |
| 7E8246 | 20 MAGNETO GP | 1 | |
| 7E8362 | 21 TUBE AS | 8 | |
| 7W4377 | 22 TRANSFORMER | 8 | |
| 7W5215 | 23 GASKET | 8 | |
| 7X6034 | 24 STRAP AS-GROUND | 1 | |
| 8M9024 | 25 WASHER-HARD (10.2X22.5X5-MM THK) | 3 | |
| 8T1895 | 26 CLIP (SLOT) | 6 | |
| 8T1896 | 27 CLIP (TAB) | 4 | |
| 9M1974 | 28 WASHER-HARD (8.8X16X2-MM THK) | 24 | |
| 9S8750 | 29 NUT-FULL (1/4-20-THD) | 8 | |
| 0910081 | 30 SPACER (10.5X20X10-MM THK) | 4 | |
| 1238641 | 31 EXTENSION AS | 8 |
