System And Components
4P-8801 WIRING GP-BOX -ELECTRIC START (CHG -00 THRU -05)PART OF 4P-5606 WIRING GP-ELECTRIC STARTING
Group No: 4P-8801
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2L8066 | 1 TERMINAL-RING (10-GA TO 12-GA, NO. 10 SCREW) | 2 | |
| 2L8068 | 2 TERMINAL-RING (10-GA TO 12-GA, 5/16-IN SCREW) | 3 | |
| 2L8071 | 3 TERMINAL-RING (10-GA TO 12-GA, 1/2-IN SCREW) | 1 | |
| 2L8075 | 4 TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 2 | |
| 2L8076 | 5 TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 2 | |
| 2N2258 | 6 RIVET-POP | 12 | |
| 2W8603 | 7 MOUNT-FLEXIBLE | 3 | |
| 2W8604 | 8 WASHER (6.5X35X1.5-MM THK) | 3 | |
| 3E0075 | 9 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 2 | |
| 1552270 | 10 KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 3F2065 | 11 LOCKNUT (1/2-14-THD) | 6 | |
| 3H4649 | 12 FITTING | 1 | |
| 3L4566 | 13 PLUG-BUTTON | 4 | |
| 3T3132 | 14 SWITCH AS-LIMIT | 1 | |
| 2H3922 | LOCKWASHER | 1 | |
| 6V8363 | SCREW (10-32X0.312-IN) | 2 | |
| 6V8370 | NUT-HEX (3/4-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 2 | |
| 9X0199 | BOOT-SWITCH | 1 | |
| 4P5224 | 15 PLATE | 1 | |
| 5N0367 | 16 FILM-IDENTIFICATION (TERMINAL MARKER) | 1 | |
| 5P1476 | 17 TERMINAL-FORK (14-GA TO 16-GA, NO. 10 SCREW) | 6 | |
| 5P4571 | 18 TERMINAL-BLADE (14-GA TO 16-GA) | 1 | |
| 6L5855 | 19 STRIP-TERMINAL | 1 | |
| 6T1780 | 20 TERMINAL | 1 | |
| 7C8782 | 21 PLATE | 1 | |
| 7N7779 | 22 SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | 23 PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | 24 HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 1863736 | 25 SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 9M9095 | 26 CONNECTOR | 4 | |
| 9X3406 | 27 RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 9X5407 | 28 SWITCH AS-BALL | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N8205 | HOUSING-PLUG | 1 | |
| 9Y1925 | 29 BOX AS | 1 | |
| 9Y6993 | 30 ADAPTER | 1 | |
| 1697294 | 31 BRACKET AS | 1 | |
| 1918395 | 32 ENCLOSURE AS (POWER DISTRIBUTION) | 1 | |
| 2008951 | 33 SEAL | 7 | |
| 2700205 | 34 BRACKET | 1 | |
| 2731005 | 35 BOX AS | 1 | |
| 2751181 | 36 WASHER | 2 | |
| 2N3480 | 37 SCREW-MACHINE (10-24X0.75-IN) | 2 | |
| 3N4809 | 39 PLUG-BUTTON | 2 | |
| 3V3308 | 40 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 4B1229 | 41 SCREW (10-24X12.7-MM) | 8 | |
| 4B2047 | 42 NUT (10-24-THD) | 2 | |
| 4P9477 | 43 GASKET | 1 | |
| 5N3174 | 44 PLUG-BUTTON | 2 | |
| 5P2675 | 45 BOLT (1/4-20X1.75-IN) | 3 | |
| 6K9591 | 46 PLUG-BUTTON | 7 | |
| 6V7699 | 47 WASHER-HARD (5.5X13X1.6-MM THK) | 8 | |
| 6V8185 | 48 NUT (1/4-20-THD) | 7 | |
| 8T4205 | 49 WASHER-HARD (7.2X14.5X2-MM THK) | 7 | |
| 9S8752 | 50 NUT-FULL (3/8-16-THD) | 4 | |
| 9X8917 | 51 SCREW-MACHINE (4-40X9.52-MM) | 4 | |
| 9X2293 | 52 CONDUIT-FLEXIBLE (12.55-MM ID)(5-CM) | ||
| 9X2293 | 52A CONDUIT-FLEXIBLE (12.55-MM ID)(29-CM) | ||
| 9X2293 | 52B CONDUIT-FLEXIBLE (12.55-MM ID)(257-CM) | ||
| 8T5346 | 53 TUBE-HEAT SHRINK (19.1-MM DIA)(20-CM) | ||
| 5P5623 | 54 WIRE-ELECTRICAL (16-GA, BLACK) | ||
| 9X2322 | 56 WIRE-ELECTRICAL (10-GA) |
