142-5015 WIRING GP-ENGINE (CHG -05 THRU -09, 163-4411-04)G3608-HYDRAX

Group No: 142-5015
Part NumberPart NameQty
0L11431 BOLT (3/8-16X2.5-IN)8
0L20702 BOLT (3/8-16X2.25-IN)12
0S05093 BOLT (3/8-16X0.75-IN)2
0S15714 BOLT (3/8-16X1.75-IN)1
0S15885 BOLT (3/8-16X1.25-IN)3
0S15906 BOLT (3/8-16X2-IN)8
0S15917 BOLT (3/8-16X1.5-IN)2
0S15948 BOLT (3/8-16X1-IN)15
0S16199 BOLT (3/8-16X3-IN)1
0T057310 BOLT (3/8-16X2.75-IN)6
1A202911 BOLT (3/8-16X1.125-IN)14
1B497112 SPACER (0.406X1X1-IN THK)2
1S099413 CLIP (LOOP)2
2A554614 BOLT (1/4-20X1.375-IN)4
2N316215 SCREW-MACHINE (10-24X1.25-IN)8
2P131416 CONNECTOR1
3B191517 BOLT (3/8-16X1.375-IN)13
3E918918 SENSOR GP-PRESSURE (PWM PRESSURE-INLET)1
3J190719 SEAL-O-RING1
3J735220 CONNECTOR1
3K036021 SEAL-O-RING1
3P076422 PLUG1
3V243123 WASHER (10.2X16X2-MM THK)4
3V330824 WASHER-HARD (10.2X20.5X2.5-MM THK)94
4B427425 WASHER (5.5X13X1.2-MM THK)6
4D738826 CLIP4
4H122527 WASHER (11X22X6-MM THK)11
4J944828 LUG4
8H070729 BOLT (1/4-20X1-IN)4
8W475530 NUT-SEALING1
4N332931 WASHER (16.25X25.65X0.79-MM)3
4P742832 CLIP (LADDER)1
4P758133 CLIP (LADDER)11
4P813434 CLIP (LADDER)6
4S196235 CLIP (LOOP)1
4S571936 SPACER (10.31X25X12.7-MM THK)5
5B263837 BOLT (3/8-16X5.25-IN)1
5N284038 CLIP3
5P053739 WASHER-HARD (7.2X14.5X2-MM THK)3
5P107540 WASHER-HARD (10.2X22.5X3-MM THK)1
5P785441 CLIP (LOOP)4
5P824542 WASHER-HARD (13.5X25.5X3-MM THK)3
5P929743 CLIP (LOOP)16
5T437544 HOSE AS1
6K919445 ELBOW2
6V231346 BOLT (M5X0.8X30-MM)6
6V458947 SEAL-O-RING1
6V504848 SEAL-O-RING7
6V504949 SEAL-O-RING8
6V764650 WASHER-HARD (7.2X25X2-MM THK)1
6V864751 CONNECTOR2
6V960152 ADAPTER1
6V987253 CONNECTOR2
7C989754 HOSE AS1
7D155355 CLIP3
7D409256 CLIP3
7D723357 CLIP (LOOP)14
7E295358 BRACKET1
7E773159 MOUNT4
7J402660 ELBOW1
7K919761 ELBOW1
7X104362 SENSOR GP-TEMPERATURE (JACKET WATER)1
7X116863 SENSOR-SPEED (TIMING CONTROL)1
8C310364 SEAL-O-RING1
8L277965 SEAL-O-RING2
8L278666 SEAL-O-RING3
8L417167 SENSOR GP-SPEED (ENGINE)(TIMING CONTROL CRANK ANGLE)1
8M277068 CLIP (LOOP)4
8M277369 CLIP (LOOP)6
8S462670 SPLICE-WIRE4
8T078871 ELBOW2
8T188772 CLIP (SLOT)1
8T188873 CLIP (TAB)1
8T328574 ADAPTER1
8T634275 TUBE-HEAT SHRINK (3.2-MM DIA)
9M459476 SPACER (0.406X0.875X0.75-IN THK)8
9S875277 NUT-FULL (3/8-16-THD)5
9W053278 SENSOR GP-TEMPERATURE (INLET)1
9W053278A SENSOR GP-TEMPERATURE (FUEL)1
9X527279 SENSOR GP-PRESSURE (STARTING AIR)1
9X677280 STRAP-CABLE20
9X677281 STRAP-CABLE
030794682 ELBOW2
030794783 ADAPTER-ELBOW1
030796184 ELBOW1
053229485 BOLT-12 POINT HEAD (3/8-16X1.75-IN)4
068994186 WIRE-TIE2
091903587 SPACER (11X25X20-MM THK)8
100783488 PLATE AS1
1F0750NUT-WELD (3/8-16-THD)2
100787089 ADAPTER-O-RING1
106915490 INSULATOR4
193551791 SENSOR GP-SPEED (ENGINE CONTROL)1
109303892 END-WIRE (16-GA)18
110871493 END-WIRE (18-GA)115
112927394 SENSOR GP-DETONATION4
114226995 SENSOR GP-TEMPERATURE (SCM OIL)1
116809296 BRACKET1
125374797 HARNESS AS (OIL TEMPERATURE)1
125374998 HARNESS AS (JACKET WATER TEMPERATURE)1
125375199 HARNESS AS (JACKET WATER TEMPERATURE)1
1253752100 HARNESS AS (OIL PRESSURE UNFILTERED)1
1253753101 HARNESS AS (OIL PRESSURE FILTERED)1
1253754102 HARNESS AS (OIL PRESSURE FILTERED)1
1253756103 HARNESS AS (CRANKCASE PRESSURE)1
1253771104 HARNESS AS-SENSOR (COMBUSTION)2
1253772105 HARNESS AS (COMBUSTION BUFFER)2
1253773106 HARNESS AS-SENSOR (COMBUSTION)2
1253774107 HARNESS AS-SENSOR (COMBUSTION)1
1253776108 HARNESS AS (OIL, WATER LEVEL)1
1253789109 HARNESS AS (FUEL TEMPERATURE)1
1253790110 HARNESS AS (STARTING AIR PRESSURE)1
1253791111 HARNESS AS (STARTING AIR SOLENOID)1
1253792112 HARNESS AS (AIR PRELUBRICATION SOLENOID)1
1253793113 HARNESS AS (CRANK ANGLE SENSOR)1
1253794114 HARNESS AS (ENGINE CONTROL MODULE)(SPEED SENSOR)1
1253795115 HARNESS AS (SPEED MAGNETIC PICKUP)1
1253796116 HARNESS AS (GAS SHUTOFF VALVE)1
1253797117 HARNESS AS-SENSOR (DETONATION)1
1253798118 HARNESS AS-SENSOR (DETONATION)1
1253799119 HARNESS AS (AIR RESTRICTION)1
1253800120 HARNESS AS (PRESSURE MODULE)1
1253801121 HARNESS AS (COMBUSTION BUFFER)1
1253802122 HARNESS AS (COMBUSTION BUFFER)1
1253804123 HARNESS AS-SENSOR (DETONATION)1
1254587124 PLATE AS1
1F0750NUT-WELD (3/8-16-THD)2
1254588125 PLATE4
1254589126 PLATE1
1257859127 BOX GP-JUNCTION (OIL/WATER LEVEL SWITCH)1
1257860128 BRACKET AS1
1257861129 SEAL9
1257875130 TUBE-HEAT SHRINK (7.44-MM DIA)
1286325131 BUSHING1
1293543132 BOX GP-JUNCTION (HYDRAX)1
1297636133 BOX GP-JUNCTION1
1323125134 COVER AS1
1356656135 HARNESS AS (ACTUATOR)1
1383132136 BRACKET1
1384409137 SPACER (10.5X22X35-MM THK)2
1409669138 SWITCH AS-PRESSURE (HYDRAX PRESSURE)1
9X1813SLEEVE (21CM)
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)3
8T8731PLUG-CONNECTOR (3-PIN)1
1425008139 HARNESS AS (FUEL HYDRAX)1
1425009140 HARNESS AS (FUEL POSITION SENSOR)1
1425010141 HARNESS AS (CHOKE HYDRAX)1
1425011142 HARNESS AS (CHOKE POSITION SENSOR)1
1425012143 HARNESS AS (WASTEGATE HYDRAX)1
1425013144 HARNESS AS (WASTEGATE POSITION SENSOR)1
1425014145 HARNESS AS (HYDRAX OIL PRESSURE SWITCH)1
1457982146 SENSOR AS (CAM POSITION)1
1461807147 HARNESS AS (CIS CAM ANGLE)1
1461808148 HARNESS AS (CIS CONTROL SIGNALS)1
1461809149 HARNESS AS (CIS POWER)1
1466672150 HARNESS AS-SENSOR (DETONATION)1
1466673151 HARNESS AS-SENSOR (DETONATION)1
1521959152 SWITCH AS-PRESSURE (PRELUBE PRESSURE)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
8T8732RECEPTACLE-CONNECTOR (3-PIN)1
9G3695PLUG-SEAL1
1564311153 TUBE AS1
1564312154 TUBE AS1
1599009155 CONTROL GP-GAS PRESSURE1
1618931156 SENSOR GP-POSITION (FUEL ACTUATOR)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
8T8732RECEPTACLE-CONNECTOR (3-PIN)1
1618931156A SENSOR GP-POSITION (CHOKE ACTUATOR)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
8T8732RECEPTACLE-CONNECTOR (3-PIN)1
1618931156B SENSOR GP-POSITION (WASTE GATE ACTUATOR)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
8T8732RECEPTACLE-CONNECTOR (3-PIN)1
1620275157 SENSOR GP-PRESSURE1
1631209158 BUSHING1
1638516159 SENSOR GP-PRESSURE (SCM OIL FILTERED)1
1643692160 SENSOR GP-PRESSURE (CMS OIL FILTERED)1
1643692160A SENSOR GP-PRESSURE (CMS OIL UNFILTERED)1
1749025161 HARNESS AS-WIRING (ENGINE PRELUBRICATION)1
9X3495162 CLIP AS1
4N5756163 BRACKET1
