4P-5802 WIRING GP-SENSOR (CHG -01 THRU -05, -05D1)WITH AIR START

Group No: 4P-5802
Part NumberPart NameQty
7E70951 HARNESS AS1
5P92972 CLIP (LOOP)5
6K49343 CLIP (SLOT)4
6K49354 CLIP (TAB)4
0L20705 BOLT (3/8-16X2.25-IN)9
3V33086 WASHER-HARD (10.2X20.5X2.5-MM THK)37
1B49717 SPACER (0.406X1X1-IN THK)5
5P78548 CLIP (LOOP)5
9Y73919 CLAMP8
0S157110 BOLT (3/8-16X1.75-IN)4
7E295211 HARNESS AS (WIRING)1
5P236912 CLIP (LOOP)7
103936913 COUPLING-SHAFT2
0L135214 BOLT (3/8-16X3.25-IN)12
103939715 CLAMP2
0S158816 BOLT (3/8-16X1.25-IN)12
7E132117 BRACKET AS2
7E132018 BRACKET AS2
7E711419 HARNESS AS-SENSOR1
112092320 HARNESS AS-WIRING1
1S099421 CLIP (LOOP)3
0S050922 BOLT (3/8-16X0.75-IN)1
112092423 HARNESS AS-WIRING1
112093224 HARNESS AS-WIRING1
5P107525 WASHER-HARD (10.2X22.5X3-MM THK)13
9S875226 NUT-FULL (3/8-16-THD)4
7E295327 BRACKET1
0S159428 BOLT (3/8-16X1-IN)3
7E295429 BRACKET1
7K570730 U-BOLT2
3S209331 STRAP-CABLE10
4P742932 CLIP (LADDER)1
4P758133 CLIP (LADDER)2
9X677234 STRAP-CABLE3
4P813435 CLIP (LADDER)2
0S050936 BOLT (3/8-16X0.75-IN)2
3V330837 WASHER-HARD (10.2X20.5X2.5-MM THK)13
5P929738 CLIP (LOOP)6
0S158839 BOLT (3/8-16X1.25-IN)3
9S875240 NUT-FULL (3/8-16-THD)5
104688141 BRACKET AS1
0S159442 BOLT (3/8-16X1-IN)4
104688243 BRACKET AS1
4K108644 U-BOLT1
5P107545 WASHER-HARD (10.2X22.5X3-MM THK)4
0S162146 BOLT (1/2-13X1-IN)2
5P824547 WASHER-HARD (13.5X25.5X3-MM THK)2
6K493448 CLIP (SLOT)2
6K493549 CLIP (TAB)2
9X677250 STRAP-CABLE2
109303951 END-WIRE (12-GA)6
110519352 END-WIRE (16-GA)75
110519453 END-WIRE (14-GA)21
