System And Components
213-6284 BOX GP-CONTROL PANEL (CHG -03, 213-6285-02)PART OF 235-5744 CONVERSION AR-ENGINE, 392-3179, 392-3180 KIT-ENGINE CONVERSION
Group No: 213-6284
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S9593 | 1 STRAP-CABLE | 11 | |
| 2W6090 | 2 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 3E0105 | 3 MOUNT | 4 | |
| 6I1418 | 4 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 7K1181 | 5 STRAP-CABLE | 1 | |
| 7R3029 | 6 CAP-DUST | 1 | |
| 8L8413 | 7 STRAP-CABLE (WHITE) | 2 | |
| 8T9655 | 8 MOUNT-ISOLATION | 8 | |
| 9X9675 | 9 BRACKET-END | 2 | |
| 1057543 | 10 BLOCK-FUSE | 2 | |
| 1059161 | 11 CAP-DUST | 1 | |
| 1096507 | 12 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 1103890 | 13 TERMINAL | 2 | |
| 1103891 | 14 COVER-END | 1 | |
| 1111324 | 15 BLOCK-CONTACT (1-POLE) | 1 | |
| 1243176 | 16 COVER | 1 | |
| 1312639 | 17 WASHER (3.2X9X0.5-MM THK) | 1 | |
| 1314888 | 18 GASKET | 1 | |
| 1328487 | 19 NUT-RING | 1 | |
| 1833192 | 20 SEAL AS (CONDUIT HOLE) | 2 | |
| 1970064 | 21 BOX AS-JUNCTION | 1 | |
| 1976949 | 22 STRIP-CONTACT | 1 | |
| 2075403 | 23 BAR-MOUNTING | 1 | |
| 2103936 | 24 BAR-MOUNTING | 1 | |
| 2109470 | 25 CONTROL GP-ENGINE ELECTRONIC | 1 | |
| 2136285 | 26 HARNESS AS-PANEL | 1 | |
| 6K0806 | STRAP-CABLE | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.02-M) | ||
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 142 | |
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 98 | |
| 9D5421 | RECEPTACLE AS-CONNECTOR (10-PIN) | 1 | |
| 9X5609 | RECEPTACLE AS-CONNECTOR (47-PIN) | 1 | |
| 1039425 | SCREW-MACHINE (8-32X1-IN) | 8 | |
| 1338753 | RECEPTACLE AS-CONNECTOR (70-PIN) | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1471443 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1261766 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 1607689 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 1607690 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 2212498 | 27 WIRE AS (8-GA, BLACK) | 1 | |
| 2338091 | 28 FUSE (6-AMPERE) | 1 | |
| 2354861 | 29 TERMINAL-GROUND | 1 | |
| 0365774 | 31 FUSE (15-AMPERE) | 1 | |
| 5P0537 | 32 WASHER-HARD (7.2X14.5X2-MM THK) | 11 | |
| 5P4115 | 33 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 8C8560 | 34 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 9S8750 | 35 NUT-FULL (1/4-20-THD) | 11 | |
| 9X6258 | 36 SCREW-MACHINE (6-32X0.5-IN) | 1 |
