System And Components
105-3184 HOUSING GP-FLYWHEEL (CHG -07 THRU -12)
Group No: 105-3184
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0335 | 1 COVER | 1 | |
| 4P0336 | 2 COVER | 1 | |
| 4P0340 | 3 GASKET | 1 | |
| 4P0388 | 4 BRACKET AS | 1 | |
| 4W6637 | 5 COVER | 2 | |
| 4W6638 | 6 GASKET | 2 | |
| 4W9653 | 7 GASKET | 1 | |
| 7E0729 | 8 COVER-TOP FACE | 1 | |
| 2845208 | 9 HOUSING-REAR | 1 | |
| 1162480 | 10 GASKET | 1 | |
| 0S1585 | 11 BOLT (1/2-13X1.5-IN) | 1 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 3 | |
| 0S1591 | 13 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 10 | |
| 2411855 | 15 BOLT (1/2-13X2-IN) | 20 | |
| 1A2029 | 16 BOLT (3/8-16X1.125-IN) | 16 | |
| 2H3756 | 17 BOLT (5/8-11X9-IN) | 4 | |
| 3V3308 | 18 WASHER-HARD (10.2X20.5X2.5-MM THK) | 34 | |
| 5P7813 | 19 SEAL-O-RING | 2 | |
| 5P8245 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 21 | |
| 5P8247 | 21 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 6V3955 | 22 SEAL-O-RING | 3 | |
| 6V5049 | 23 SEAL-O-RING | 2 | |
| 6V9608 | 24 BOLT (5/8-11X10-IN) | 10 | |
| 8C3103 | 25 SEAL-O-RING | 1 | |
| 9S8004 | 26 PLUG (9/16-18-THD) | 2 | |
| 9S8007 | 27 PLUG (3/8-24-THD) | 2 | |
| 2884408 | 28 GASKET | 1 | |
| 2884409 | 29 COVER | 1 | |
| 0L1351 | 30 BOLT (3/8-16X0.875-IN) | 4 |
