System And Components
119-5006 LINES GP-WATER (CHG -01)TWO STAGE AFTERCOOLER, SERIES
Group No: 119-5006
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A2161 | 1 SPACER (0.4X0.875X0.381-IN) | 2 | |
| 1W4059 | 2 COVER | 1 | |
| 2N1117 | 3 CLIP | 1 | |
| 5R9779 | 4 GASKET | 4 | |
| 7E7209 | 5 RING-RETAINING | 1 | |
| 7W3269 | 6 GASKET | 1 | |
| 9X8882 | 7 BOLT (5/8-11X2.5-IN) | 8 | |
| 1074862 | 8 PLATE | 1 | |
| 1112556 | 9 GASKET | 1 | |
| 1190956 | 10 TUBE AS | 1 | |
| 1195012 | 11 TUBE AS | 1 | |
| 1246333 | 12 CLAMP AS | 2 | |
| 1347429 | 13 TUBE AS | 1 | |
| 1409708 | 14 BRACKET AS | 1 | |
| 1409711 | 15 FLANGE | 1 | |
| 1409744 | 16 TUBE AS | 1 | |
| 0S1571 | 17 BOLT (3/8-16X1.75-IN) | 8 | |
| 0S1588 | 18 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1589 | 19 BOLT (5/8-11X1.75-IN) | 8 | |
| 0S1590 | 20 BOLT (3/8-16X2-IN) | 3 | |
| 0S1594 | 21 BOLT (3/8-16X1-IN) | 2 | |
| 3V3308 | 22 WASHER-HARD (10.2X20.5X2.5-MM THK) | 21 | |
| 4B4043 | 23 BOLT (5/8-11X1.375-IN) | 8 | |
| 4K0367 | 24 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8247 | 25 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 6V1454 | 26 SEAL-O-RING | 1 | |
| 6V5504 | 27 SEAL-O-RING | 1 | |
| 8M9024 | 28 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 8T6760 | 29 PLUG-PIPE (1-1/2-11-1/2 NPT) | 1 | |
| 8T6762 | 30 PLUG-PIPE (1/2-14-THD) | 6 | |
| 9S8752 | 31 NUT-FULL (3/8-16-THD) | 7 | |
| 9X2646 | 32 CLIP (SLOT) | 1 | |
| 9X2647 | 33 CLIP (TAB) | 1 |
