System And Components
119-5006 LINES GP-WATER (CHG -02)TWO STAGE AFTERCOOLER, SERIES
Group No: 119-5006
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4059 | 1 COVER | 1 | |
| 2N1117 | 2 CLIP | 1 | |
| 4P9224 | 3 COVER | 1 | |
| 5R9779 | 4 GASKET | 4 | |
| 7E7209 | 5 RING-RETAINING | 1 | |
| 7W3269 | 6 GASKET | 5 | |
| 7W6092 | 7 HOUSING | 1 | |
| 7W6998 | 8 ORIFICE | 1 | |
| 8T6760 | 9 PLUG-PIPE (1-1/2-11-1/2 NPT) | 1 | |
| 8T6765 | 10 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9X8882 | 11 BOLT (5/8-11X2.5-IN) | 8 | |
| 1112556 | 12 GASKET | 1 | |
| 1190956 | 13 TUBE AS | 1 | |
| 1246333 | 14 CLAMP AS | 2 | |
| 1347429 | 15 TUBE AS | 1 | |
| 1409711 | 16 FLANGE | 1 | |
| 1564683 | 17 BRACKET AS | 1 | |
| 1572572 | 18 TUBE AS | 1 | |
| 1575901 | 19 TUBE AS | 1 | |
| 0S1571 | 20 BOLT (3/8-16X1.75-IN) | 6 | |
| 0S1588 | 21 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1589 | 22 BOLT (5/8-11X1.75-IN) | 8 | |
| 0S1590 | 23 BOLT (3/8-16X2-IN) | 3 | |
| 0S1594 | 24 BOLT (3/8-16X1-IN) | 8 | |
| 1A2029 | 25 BOLT (3/8-16X1.125-IN) | 2 | |
| 3V3308 | 26 WASHER-HARD (10.2X20.5X2.5-MM THK) | 31 | |
| 4B4043 | 27 BOLT (5/8-11X1.375-IN) | 8 | |
| 4K0367 | 28 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8247 | 29 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 6V1454 | 30 SEAL-O-RING | 1 | |
| 6V5504 | 31 SEAL-O-RING | 1 | |
| 8M9024 | 32 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 8T6762 | 33 PLUG-PIPE (1/2-14-THD) | 7 | |
| 9S8752 | 34 NUT-FULL (3/8-16-THD) | 7 | |
| 9X2646 | 35 CLIP (SLOT) | 1 | |
| 9X2647 | 36 CLIP (TAB) | 1 |
