System And Components
133-7489 LINES GP-WATER (CHG -00, -01)
Group No: 133-7489
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W3709 | 1 ADAPTER-WATER | 1 | |
| 0S1594 | 2 BOLT (3/8-16X1-IN) | 44 | |
| 7W3272 | 3 GASKET | 1 | |
| 1S5772 | 4 GASKET | 4 | |
| 0S1591 | 5 BOLT (3/8-16X1.5-IN) | 14 | |
| 3V3308 | 6 WASHER-HARD (10.2X20.5X2.5-MM THK) | 60 | |
| 9S8752 | 7 NUT-FULL (3/8-16-THD) | 22 | |
| 1337467 | 8 TUBE AS | 1 | |
| 1168654 | 9 CONNECTION-FLEXIBLE | 2 | |
| 1A8063 | 10 BOLT (3/4-10X2.5-IN) | 28 | |
| 2J3506 | 11 NUT-FULL (3/4-10-THD) | 32 | |
| 5P8248 | 12 WASHER-HARD (20X36.5X3.5-MM THK) | 64 | |
| 1166065 | 13 FLANGE | 1 | |
| 1337468 | 14 TUBE AS | 1 | |
| 7W8465 | 15 ADAPTER-HOUSING | 1 | |
| 2W5036 | 16 TUBE | 1 | |
| 6V5139 | 17 SEAL-O-RING | 2 | |
| 7W8463 | 18 ELBOW-ADAPTER | 1 | |
| 1337482 | 19 PLATE | 1 | |
| 1A5822 | 20 BOLT (1/2-13X2.75-IN) | 2 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1337470 | 22 SUPPORT | 1 | |
| 1337473 | 23 PLATE | 2 | |
| 1337478 | 24 SUPPORT | 1 | |
| 1337476 | 25 SUPPORT | 1 | |
| 0L1143 | 26 BOLT (3/8-16X2.5-IN) | 2 | |
| 1337479 | 27 PLATE | 1 | |
| 0S1571 | 28 BOLT (3/8-16X1.75-IN) | 2 | |
| 4W9504 | 29 BRACKET | 1 | |
| 8T1586 | 30 CLIP | 2 | |
| 0S1588 | 31 BOLT (3/8-16X1.25-IN) | 4 | |
| 8T2967 | 32 JOINT AS-TUBE | 1 | |
| 6V9336 | SEAL | 1 | |
| 4W7748 | 33 TUBE AS | 1 | |
| 4W7749 | 34 GASKET | 2 | |
| 8T6762 | 35 PLUG-PIPE (1/2-14-THD) | 4 | |
| 1337483 | 36 TUBE AS | 1 | |
| 1262367 | 37 BRACKET | 1 | |
| 1230149 | 38 FLANGE | 1 | |
| 1166064 | 39 TUBE AS | 1 | |
| 1337471 | 40 SUPPORT | 1 | |
| 9X8887 | 41 BOLT (3/4-10X3-IN) | 4 |
