System And Components
140-1124 LINES GP-WATER (CHG -01, -01D1)G3612-TWO STAGE AFTERCOOLER-OCLR
Group No: 140-1124
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A2161 | 1 SPACER (0.4X0.875X0.381-IN) | 1 | |
| 1W4059 | 2 COVER | 1 | |
| 2N1117 | 3 CLIP | 3 | |
| 4P9224 | 4 COVER | 1 | |
| 5R9779 | 5 GASKET | 4 | |
| 7E7209 | 6 RING-RETAINING | 1 | |
| 7W3269 | 7 GASKET | 5 | |
| 7W6092 | 8 HOUSING | 1 | |
| 7W6998 | 9 ORIFICE | 1 | |
| 8T6760 | 10 PLUG-PIPE (1-1/2-11-1/2 NPT) | 1 | |
| 8T6765 | 11 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9X8882 | 12 BOLT (5/8-11X2.5-IN) | 16 | |
| 1074862 | 13 PLATE | 2 | |
| 1100096 | 14 RING | 1 | |
| 1112556 | 15 GASKET | 2 | |
| 1190956 | 16 TUBE AS | 1 | |
| 1221148 | 17 CLAMP AS | 2 | |
| 1246333 | 18 CLAMP AS | 2 | |
| 1282840 | 19 BRACKET AS | 1 | |
| 1347427 | 20 TUBE AS | 1 | |
| 1347429 | 21 TUBE AS | 1 | |
| 1409703 | 22 TUBE AS | 1 | |
| 1409705 | 23 TUBE AS | 1 | |
| 1409707 | 24 BRACKET AS | 1 | |
| 1409711 | 25 FLANGE | 1 | |
| 1564683 | 26 BRACKET AS | 1 | |
| 1575901 | 27 TUBE AS | 1 | |
| 0S1571 | 28 BOLT (3/8-16X1.75-IN) | 10 | |
| 0S1588 | 29 BOLT (3/8-16X1.25-IN) | 9 | |
| 0S1589 | 30 BOLT (5/8-11X1.75-IN) | 12 | |
| 0S1590 | 31 BOLT (3/8-16X2-IN) | 3 | |
| 0S1591 | 32 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 33 BOLT (3/8-16X1-IN) | 10 | |
| 1A2029 | 34 BOLT (3/8-16X1.125-IN) | 2 | |
| 3B1915 | 35 BOLT (3/8-16X1.375-IN) | 1 | |
| 3V3308 | 36 WASHER-HARD (10.2X20.5X2.5-MM THK) | 54 | |
| 4B4043 | 37 BOLT (5/8-11X1.375-IN) | 4 | |
| 4K0367 | 38 NUT-FULL (5/8-11-THD) | 16 | |
| 5P8247 | 39 WASHER-HARD (17X32X3.5-MM THK) | 48 | |
| 6V1454 | 40 SEAL-O-RING | 1 | |
| 6V5066 | 41 SEAL-O-RING | 1 | |
| 6V5504 | 42 SEAL-O-RING | 1 | |
| 8T6762 | 43 PLUG-PIPE (1/2-14-THD) | 11 | |
| 9S8752 | 44 NUT-FULL (3/8-16-THD) | 17 | |
| 9X2646 | 45 CLIP (SLOT) | 1 | |
| 9X2647 | 46 CLIP (TAB) | 1 |
