System And Components
105-3178 AFTERCOOLER GP -WATER (CHG -00 THRU -09)FOR USE WITH ESS PANEL WITH COMPUTERIZED MONITORING SYSTEM
Group No: 105-3178
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1279820 | 1 COVER | 2 | |
| 1222704 | 2 CORE AS | 2 | |
| 3P0655 | 3 SEAL-O-RING | 18 | |
| 1236331 | 4 TUBE AS | 2 | |
| 1236256 | 5 ADAPTER | 4 | |
| 6V3908 | 6 SEAL-O-RING | 4 | |
| 2W3794 | 7 ADAPTER | 2 | |
| 4W7563 | 8 SEAL | 2 | |
| 7W5905 | 9 HOUSING | 2 | |
| 0S1591 | 10 BOLT (3/8-16X1.5-IN) | 52 | |
| 3V3308 | 11 WASHER-HARD (10.2X20.5X2.5-MM THK) | 176 | |
| 1213874 | 12 GASKET | 6 | |
| 3P0657 | 13 SEAL-O-RING | 4 | |
| 0S1571 | 14 BOLT (3/8-16X1.75-IN) | 8 | |
| 2W4769 | 15 SPACER | 1 | |
| 2W4766 | 16 GASKET | 1 | |
| 2W4027 | 17 PIPE | 2 | |
| 0S1588 | 18 BOLT (3/8-16X1.25-IN) | 15 | |
| 6V5051 | 19 SEAL-O-RING | 2 | |
| 4W7555 | 20 ADAPTER | 2 | |
| 2W3789 | 21 PIPE | 2 | |
| 4W7557 | 22 COVER | 2 | |
| 0S1619 | 23 BOLT (3/8-16X3-IN) | 83 | |
| 8B2026 | SPACER (0.438X0.75X1.5-IN THK) | 83 | |
| 9S4191 | 24 PLUG (9/16-18-THD) | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 0L2070 | 25 BOLT (3/8-16X2.25-IN) | 14 | |
| 0L1352 | 26 BOLT (3/8-16X3.25-IN) | 6 | |
| 0S1590 | 27 BOLT (3/8-16X2-IN) | 24 | |
| 1356950 | 28 SEAL-O-RING | 8 | |
| 7W5130 | 29 PIPE | 2 | |
| 2W3791 | 30 PIPE | 2 | |
| 2W4031 | 31 COVER | 2 | |
| 3E6751 | 32 SEAL-O-RING | 2 | |
| 7W5528 | 33 ELBOW | 1 | |
| 7W6333 | 34 SPACER (10.5X20X10.7-MM THK) | 8 | |
| 7E6211 | 35 ELBOW | 1 | |
| 8T6766 | 36 PLUG-PIPE | 2 | |
| 9S4185 | 37 PLUG (3/4-16-THD) | 3 | |
| 8L2786 | 38 SEAL-O-RING | 3 | |
| 4W9510 | 39 COVER | 1 | |
| 7C0109 | 40 GASKET | 1 | |
| 7N5352 | 41 DOWEL | 2 |
