System And Components
131-0528 BYPASS GP-EXHAUST (CHG -02)TWO STAGE AFTERCOOLER
Group No: 131-0528
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W6963 | 1 GASKET | 2 | |
| 2N2766 | 2 LOCKNUT (3/8-16-THD) | 62 | |
| 6V3630 | 3 BOLT-HIGH TEMPERATURE (1/2-13X2.5-IN) | 8 | |
| 6V8735 | 4 CAP | 2 | |
| 7C2144 | 5 GASKET | 2 | |
| 7E0701 | 6 GASKET | 5 | |
| 7L6443 | 7 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN) | 62 | |
| 8C8491 | 8 WASHER-HARD (10.2X22X3-MM THK) | 124 | |
| 8C8763 | 9 LOCKNUT (1/2-13-THD) | 8 | |
| 9Y3099 | 10 GASKET | 2 | |
| 1235717 | 11 BELLOWS AS | 1 | |
| 1244383 | 12 ADAPTER | 2 | |
| 1268775 | 13 MANIFOLD-EXHAUST (LH) | 1 | |
| 1268776 | 14 MANIFOLD-EXHAUST (RH) | 1 | |
| 1268777 | 15 MANIFOLD-EXHAUST (BYPASS) | 1 | |
| 1268778 | 16 MANIFOLD-EXHAUST (WASTEGATE) | 1 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 16 |
