System And Components
100-8359 LINES GP-AIR (CHG -00 THRU -04)AIR INLET CHOKE
Group No: 100-8359
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S4191 | 1 PLUG (9/16-18-THD) | 2 | |
| 6V5049 | SEAL-O-RING | 2 | |
| 0321768 | 2 SETSCREW (3/8-16-THD) | 1 | |
| 7W7629 | 3 HOUSING | 1 | |
| 7W6340 | 4 GASKET | 2 | |
| 7W7625 | 5 HOUSING | 1 | |
| 6V5095 | 6 SEAL-O-RING | 8 | |
| 4W7516 | 7 ELBOW (RH) | 1 | |
| 6V5102 | 8 SEAL-O-RING | 2 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 22 | |
| 1F7958 | 10 NUT-FULL (1/2-13-THD) | 12 | |
| 0S1587 | 11 BOLT (1/2-13X1.75-IN) | 4 | |
| 4W7515 | 12 ELBOW (LH) | 1 | |
| 4W7392 | 13 PIPE | 2 | |
| 0S1591 | 14 BOLT (3/8-16X1.5-IN) | 32 | |
| 3V3308 | 15 WASHER-HARD (10.2X20.5X2.5-MM THK) | 75 | |
| 6I0733 | 16 HOUSING AS | 1 | |
| 6V5041 | SEAL-LIP TYPE | 2 | |
| 7E6553 | BUSHING | 2 | |
| 2W4766 | 17 GASKET | 1 | |
| 6I0581 | 18 ACTUATOR GP-ELECTRONIC | 1 | |
| 7C8454 | 19 PLATE-BUTTERFLY | 1 | |
| 6I1644 | 20 WASHER-THRUST | 1 | |
| 6I1645 | 21 SHAFT | 1 | |
| 0315085 | 22 BOLT-LOCKING (1/4-20X1-IN) | 4 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 6 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 6 | |
| 7X7875 | 25 ROD END | 2 | |
| 3S2713 | 26 NUT-FULL (3/8-24-THD) | 5 | |
| 6I1643 | 27 COVER AS | 1 | |
| 1S3584 | 28 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 7X7874 | 29 ROD END | 2 | |
| 0S1588 | 30 BOLT (3/8-16X1.25-IN) | 18 | |
| 5L3291 | 31 BEARING AS-BALL | 2 | |
| 1010129 | 32 SHAFT | 1 | |
| 6I4237 | 33 BRACKET AS | 1 | |
| 6I4236 | 34 BRACKET AS | 1 | |
| 9S8752 | 35 NUT-FULL (3/8-16-THD) | 16 | |
| 8M9024 | 36 WASHER-HARD (10.2X22.5X5-MM THK) | 6 | |
| 5H2532 | 37 KEY-WOODRUFF | 3 | |
| 6I2520 | 38 LEVER | 1 | |
| 0S1571 | 39 BOLT (3/8-16X1.75-IN) | 4 | |
| 1010128 | 40 BRACKET | 1 | |
| 5P8245 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 1010131 | 42 BRACKET-MOUNTING | 1 | |
| 9M1974 | 43 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 6V2317 | BOLT (M8X1.25X30-MM) | 4 | |
| 6I1642 | 44 PLATE | 1 | |
| 1010130 | 45 COVER-SUPPORT | 1 | |
| 4P0340 | 46 GASKET | 1 | |
| 4P0390 | 47 ROD | 1 | |
| 6I2522 | 48 LEVER | 1 | |
| 1A9579 | 49 BOLT (5/16-18X1.5-IN) | 1 | |
| 5S0003 | 50 NUT (5/16-18-THD) | 1 | |
| 6I1641 | 51 PLATE | 1 | |
| 4P0394 | 52 LEVER | 2 | |
| 1010243 | 53 ROD | 1 | |
| 0S1595 | 54 BOLT (1/2-13X1.25-IN) | 1 | |
| 9X8887 | 55 BOLT (3/4-10X3-IN) | 1 | |
| 5P8248 | 56 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 7C1178 | 57 CLEVIS | 1 | |
| 2D6235 | 58 LOCKNUT (1/4-20-THD) | 2 | |
| 5P0537 | 59 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1B4427 | 60 NUT-JAM (1/4-20-THD) | 2 | |
| 1167671 | 61 SPRING-EXTENSION | 1 | |
| 1102974 | 62 ROD-THREADED | 1 | |
| 9L7712 | 63 NUT (3/8-24-THD) | 1 | |
| 1S4244 | 64 PIN (9.4-MM OD) | 1 | |
| 3B4617 | 65 PIN-COTTER | 1 | |
| 1102964 | 66 BRACKET AS | 1 | |
| 1174549 | 67 BRACKET AS | 1 | |
| 9L0945 | 68 U-BOLT | 1 | |
| 9X8873 | 69 BOLT (1/2-13X2.25-IN) | 10 | |
| 9S1366 | 70 BOLT (1/2-13X2.5-IN) | 2 | |
| 9X8888 | 71 BOLT (3/4-10X3.25-IN) | 1 |
