System And Components
195-3912 LINES GP-AIR (CHG -03)AIR INLET CHOKE
Group No: 195-3912
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S3584 | 1 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 2W4766 | 2 GASKET | 1 | |
| 3S2713 | 3 NUT-FULL (3/8-24-THD) | 2 | |
| 4E2250 | 4 HOUSING | 1 | |
| 4P0390 | 5 ROD | 1 | |
| 4P0394 | 6 LEVER | 3 | |
| 5H2532 | 7 KEY-WOODRUFF | 3 | |
| 5L3291 | 8 BEARING AS-BALL | 2 | |
| 6D3025 | 9 BALL BEARING | 2 | |
| 6I0733 | 10 HOUSING AS | 1 | |
| 6V5041 | SEAL-LIP TYPE | 2 | |
| 1611201 | BUSHING | 2 | |
| 6I1641 | 11 PLATE | 1 | |
| 6I1642 | 12 PLATE | 1 | |
| 6I1643 | 13 COVER AS | 1 | |
| 6I1644 | 14 WASHER-THRUST | 1 | |
| 6I1645 | 15 SHAFT | 1 | |
| 7C8454 | 16 PLATE-BUTTERFLY | 1 | |
| 7E1630 | 17 GASKET | 1 | |
| 7W6340 | 18 GASKET | 2 | |
| 8C5607 | 19 MOUNT-ISOLATION | 6 | |
| 8C5608 | 20 SPACER (6.5X9.5X25.4-MM THK) | 3 | |
| 8C7315 | 21 ROD END | 2 | |
| 8C7321 | 22 ROD END | 2 | |
| 8H3390 | 23 NUT-FULL (1-1/2-12-THD) | 1 | |
| 9U3300 | 24 SPACER (7X25X50-MM THK) | 3 | |
| 0321768 | 25 SETSCREW (3/8-16-THD) | 1 | |
| 1183842 | 26 BRACKET AS | 1 | |
| 1183843 | 27 SHAFT | 1 | |
| 1223360 | 28 BRACKET | 1 | |
| 1271573 | 29 SHAFT | 1 | |
| 1450039 | 30 BRACKET AS | 1 | |
| 1450040 | 31 BRACKET AS | 1 | |
| 1450041 | 32 ROD | 1 | |
| 1763572 | 33 COUPLING GP-SHAFT | 1 | |
| 1763583 | 34 GUARD | 2 | |
| 1763587 | 35 CLEVIS | 1 | |
| 1808408 | 36 ADAPTER | 1 | |
| 1837232 | 37 BELLOWS AS | 2 | |
| 1846379 | 38 HOUSING | 1 | |
| 1937879 | 39 BOOT | 1 | |
| 1969529 | 40 ACTUATOR GP-ELECTRONIC | 1 | |
| 1978120 | 41 GASKET | 4 | |
| 0315085 | 42 BOLT-LOCKING (1/4-20X1-IN) | 4 | |
| 0S1566 | 43 BOLT (5/8-11X1.5-IN) | 12 | |
| 0S1571 | 44 BOLT (3/8-16X1.75-IN) | 22 | |
| 0S1587 | 45 BOLT (1/2-13X1.75-IN) | 1 | |
| 0S1588 | 46 BOLT (3/8-16X1.25-IN) | 12 | |
| 0S1589 | 47 BOLT (5/8-11X1.75-IN) | 10 | |
| 0S1590 | 48 BOLT (3/8-16X2-IN) | 5 | |
| 0S1591 | 49 BOLT (3/8-16X1.5-IN) | 12 | |
| 0S1594 | 50 BOLT (3/8-16X1-IN) | 6 | |
| 1A9579 | 51 BOLT (5/16-18X1.5-IN) | 1 | |
| 1F7958 | 52 NUT-FULL (1/2-13-THD) | 2 | |
| 1J8668 | 53 STUD-TAPERLOCK (3/8-16X1.97-IN) | 4 | |
| 2H3429 | 54 RING-RETAINING | 1 | |
| 2L6726 | 55 RING-RETAINING | 1 | |
| 3V3308 | 56 WASHER-HARD (10.2X20.5X2.5-MM THK) | 76 | |
| 5P8245 | 57 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 5P8247 | 58 WASHER-HARD (17X32X3.5-MM THK) | 22 | |
| 5S0003 | 59 NUT (5/16-18-THD) | 1 | |
| 6V5049 | 60 SEAL-O-RING | 2 | |
| 8B7997 | 61 BOLT-SOCKET HEAD (1/2-13X2-IN) | 2 | |
| 8F6302 | 62 BOLT (1/4-20X3.75-IN) | 3 | |
| 8M2337 | 63 WASHER (7.2X24.5X3-MM THK) | 6 | |
| 8M9024 | 64 WASHER-HARD (10.2X22.5X5-MM THK) | 3 | |
| 9S4191 | 65 PLUG (9/16-18-THD) | 2 | |
| 9S8752 | 66 NUT-FULL (3/8-16-THD) | 21 |
