System And Components
156-0268 CONTROL GP-FUEL (CHG -07, -07D2, -08, -08D1, -08D2)GAS
Group No: 156-0268
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S3584 | 1 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 1W3557 | 2 GASKET | 1 | |
| 3S2713 | 3 NUT-FULL (3/8-24-THD) | 2 | |
| 4D8532 | 4 LEVER | 1 | |
| 4E2250 | 5 HOUSING | 1 | |
| 4P0391 | 6 ROD | 1 | |
| 5H2532 | 7 KEY-WOODRUFF | 2 | |
| 5L3291 | 8 BEARING AS-BALL | 2 | |
| 6D3025 | 9 BALL BEARING | 2 | |
| 7E1630 | 10 GASKET | 1 | |
| 8C5607 | 11 MOUNT-ISOLATION | 6 | |
| 8C5608 | 12 SPACER (6.5X9.5X25.4-MM THK) | 3 | |
| 8C6971 | 13 ROD END | 1 | |
| 8C7315 | 14 ROD END | 1 | |
| 8C7321 | 15 ROD END | 2 | |
| 8H3390 | 16 NUT-FULL (1-1/2-12-THD) | 1 | |
| 9U3300 | 17 SPACER (7X25X50-MM THK) | 3 | |
| 1157768 | 18 LEVER | 1 | |
| 1186662 | 19 BRACKET AS | 1 | |
| 1186663 | 20 BRACKET AS | 1 | |
| 1186664 | 21 BRACKET AS | 1 | |
| 1186665 | 22 SHAFT | 1 | |
| 1257861 | 23 SEAL | 1 | |
| 1271573 | 24 SHAFT | 1 | |
| 1281204 | 25 VALVE GP-GAS CONTROL | 1 | |
| 1281205 | 26 TUBE AS | 1 | |
| 1763572 | 27 COUPLING GP-SHAFT | 1 | |
| 1763583 | 28 GUARD | 2 | |
| 1763587 | 29 CLEVIS | 2 | |
| 1937879 | 30 BOOT | 1 | |
| 2118175 | 31 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC) | 1 | |
| 0336031 | 32 SEAL-O-RING | 1 | |
| 0S1571 | 33 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1588 | 34 BOLT (3/8-16X1.25-IN) | 12 | |
| 0S1590 | 35 BOLT (3/8-16X2-IN) | 2 | |
| 0S1591 | 36 BOLT (3/8-16X1.5-IN) | 4 | |
| 1F7958 | 37 NUT-FULL (1/2-13-THD) | 4 | |
| 2H3429 | 38 RING-RETAINING | 1 | |
| 2L6726 | 39 RING-RETAINING | 1 | |
| 3V3308 | 40 WASHER-HARD (10.2X20.5X2.5-MM THK) | 34 | |
| 5P8245 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 5P8248 | 42 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 6V3940 | 43 BOLT (M8X1.25X25-MM) | 4 | |
| 6V8002 | 44 SEAL-O-RING | 1 | |
| 8F6302 | 45 BOLT (1/4-20X3.75-IN) | 3 | |
| 8M2337 | 46 WASHER (7.2X24.5X3-MM THK) | 6 | |
| 8M9024 | 47 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9M1974 | 48 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8752 | 49 NUT-FULL (3/8-16-THD) | 13 | |
| 9X8873 | 50 BOLT (1/2-13X2.25-IN) | 4 | |
| 9X8887 | 51 BOLT (3/4-10X3-IN) | 4 | |
| 0L1143 | 52 BOLT (3/8-16X2.5-IN) | 4 | |
| 4P6945 | KIT-VALVE REPAIR | 1 | |
| 4P6542 | KIT-VALVE GASKET | 1 | |
| 4P6543 | KIT-VALVE SEAL | 1 |
