System And Components
205-7307 CONTROL GP-FUEL (CHG -01-03 THRU -06)
Group No: 205-7307
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1565320 | 1 BRACKET AS | 1 | |
| 1S3584 | 2 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 1W3557 | 3 GASKET | 1 | |
| 3S2713 | 4 NUT-FULL (3/8-24-THD) | 2 | |
| 4D8532 | 5 LEVER | 1 | |
| 5H2532 | 6 KEY-WOODRUFF | 2 | |
| 5L3291 | 7 BEARING AS-BALL | 2 | |
| 6I2520 | 8 LEVER | 1 | |
| 8C7315 | 9 ROD END | 2 | |
| 8C7321 | 10 ROD END | 2 | |
| 8H3390 | 11 NUT-FULL (1-1/2-12-THD) | 1 | |
| 9Y8490 | 12 ROD | 1 | |
| 1186664 | 13 BRACKET AS | 1 | |
| 3713653 | 14 TUBE AS | 1 | |
| 1450041 | 15 ROD | 1 | |
| 1560269 | 16 CLEVIS | 1 | |
| 1560270 | 17 VALVE GP-GAS CONTROL | 1 | |
| 1763583 | 18 GUARD | 2 | |
| 1763587 | 19 CLEVIS | 1 | |
| 1937879 | 20 BOOT | 1 | |
| 2057309 | 21 BRACKET AS | 1 | |
| 2057310 | 22 SHAFT | 1 | |
| 2118175 | 23 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC) | 1 | |
| 3512247 | 24 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1571 | 25 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 26 BOLT (3/8-16X1.25-IN) | 13 | |
| 0S1590 | 27 BOLT (3/8-16X2-IN) | 2 | |
| 0S1591 | 28 BOLT (3/8-16X1.5-IN) | 4 | |
| 3V3308 | 29 WASHER-HARD (10.2X20.5X2.5-MM THK) | 35 | |
| 4K0367 | 30 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8247 | 31 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 5P8248 | 32 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 6V3940 | 33 BOLT (M8X1.25X25-MM) | 2 | |
| 6V8002 | 34 SEAL-O-RING | 1 | |
| 7X3374 | 35 NUT-FULL (1/2-20-THD) | 1 | |
| 8M9024 | 36 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9M1974 | 37 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8752 | 38 NUT-FULL (3/8-16-THD) | 12 | |
| 9X8883 | 39 BOLT (5/8-11X2.75-IN) | 8 | |
| 9X8887 | 40 BOLT (3/4-10X3-IN) | 4 | |
| 3878278 | 41 GASKET | 1 | |
| 1198266 | KIT-VALVE GASKET | 1 | |
| 1198267 | KIT-VALVE SEAL | 1 | |
| 1198268 | KIT-VALVE REPAIR | 1 |
