System And Components
122-0803 BOX GP-JUNCTION (CHG -00, -01)PART OF 117-5307 SCHEMATIC & COMPONENT GP
Group No: 122-0803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1220796 | 1 DUCT-WIRE (65CM) | ||
| 1220797 | 2 COVER-DUCT (65CM) | ||
| 1220798 | 3 DUCT-WIRE (185CM) | ||
| 1220799 | 4 COVER-DUCT (185CM) | ||
| 1220800 | 5 PANEL AS | 1 | |
| 1220801 | 6 HARNESS AS-BOX | 1 | |
| 1220802 | 7 BOX AS-JUNCTION | 1 | |
| 7E0717 | LATCH AS-DOOR | 2 | |
| 9X6442 | SEAL (258CM) | ||
| 6L7159 | 8 SCREW-MACHINE (8-32X0.313-IN) | 30 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 4 | |
| 3V3308 | 10 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 1B2714 | 11 BOLT (1/4-20X2.5-IN) | 2 | |
| 5P0537 | 12 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8C8560 | 13 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 5S4246 | 14 LOCKWASHER | 4 | |
| 6B4540 | 15 NUT (4-40-THD) | 4 | |
| 8D9537 | 16 CAP-DUST | 1 | |
| 4P4251 | 17 GASKET | 1 | |
| 3E0105 | 18 MOUNT | 3 | |
| 1152538 | 19 COVER-END | 5 | |
| 1151322 | 20 TERMINAL (DOUBLE) | 101 | |
| 3E0368 | 21 STRIP-CONTACT | 11 | |
| 9X9675 | 22 BRACKET-END | 4 | |
| 1103891 | 23 COVER-END | 1 | |
| 1061826 | 24 TERMINAL | 4 | |
| 1072701 | 25 STRIP-CONTACT | 1 | |
| 9X9616 | 26 COVER-END | 4 | |
| 9X9615 | 27 TERMINAL (SINGLE) | 7 | |
| 3E0356 | 28 BLOCK-TERMINAL | 3 | |
| 3E0357 | 29 DIODE AS | 1 | |
| 1057543 | 30 BLOCK-FUSE | 5 | |
| 1057542 | 31 STRIP-CONTACT | 1 | |
| 1096539 | 32 PLATE-SEPARATOR | 1 | |
| 5N4988 | 33 DIODE AS | 1 | |
| 5P1475 | TERMINAL-FORK (14-GA TO 16-GA, NO. 8 SCREW) | 2 | |
| 3E0456 | 34 RELAY AS | 1 | |
| 1057541 | 35 SPRING-RELAY | 1 | |
| 6K0806 | 36 STRAP-CABLE | 1 | |
| 1057540 | 37 SOCKET-RELAY | 1 | |
| 1287375 | 38 CONTROL GP-ENGINE MONITORING | 1 | |
| 8L8413 | 39 STRAP-CABLE (WHITE) | 1 | |
| 9X9614 | 40 TERMINAL (SINGLE) | 6 | |
| 1271574 | 41 STRIP-CONTACT | 1 | |
| 1152542 | 42 PLUG | 2 | |
| 7G0020 | 43 RESISTOR | 1 | |
| 3T9377 | 44 RESISTOR | 1 | |
| 1280937 | 45 TERMINAL | 18 | |
| 1165193 | 46 COVER-END | 1 | |
| 1165137 | 47 SPACER (TERMINAL) | 1 | |
| 1S9593 | 48 STRAP-CABLE | 2 | |
| 2W6090 | 49 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 1096507 | 50 SWITCH AS-PUSH BUTTON | 1 | |
| 1271626 | 51 BLOCK-CONTACT | 1 | |
| 1152945 | 52 KIT-MARKER | 1 | |
| 3K8782 | 53 FUSE (10-AMPERE) | 5 | |
| 1057692 | 54 ISOLATOR | 42 | |
| 1057693 | 55 ISOLATOR | 3 | |
| 1271682 | KIT-MARKER | 1 |
