System And Components
122-0803 BOX GP-JUNCTION (CHG -02 THRU -04)PART OF 117-5307 SCHEMATIC & COMPONENT GP
Group No: 122-0803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1615 | 1 BOLT (1/4-20X0.75-IN) | 3 | |
| 1B2714 | 2 BOLT (1/4-20X2.5-IN) | 2 | |
| 1S9593 | 3 STRAP-CABLE | 2 | |
| 2W6090 | 4 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 3E0105 | 5 MOUNT | 3 | |
| 3E0356 | 6 BLOCK-TERMINAL | 4 | |
| 3E0357 | 7 DIODE AS | 1 | |
| 3E0368 | 8 STRIP-CONTACT | 11 | |
| 3E3566 | 9 BRIDGE-INSERTION | 1 | |
| 9Y6027 | 10 FUSE-CERAMIC (10-AMPERE) | 5 | |
| 3T9377 | 11 RESISTOR | 1 | |
| 3V3308 | 12 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 4P4251 | 13 GASKET | 1 | |
| 5P0537 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 5S4246 | 15 LOCKWASHER | 4 | |
| 6B4540 | 16 NUT (4-40-THD) | 4 | |
| 7G0020 | 17 RESISTOR | 2 | |
| 7S1201 | 18 SCREW-MACHINE (8-32X0.375-IN) | 33 | |
| 8C8560 | 19 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 8D9537 | 20 CAP-DUST | 1 | |
| 8T1296 | 21 WASHER (10.5X19X3.5-MM THK) | 1 | |
| 8L8413 | 22 STRAP-CABLE (WHITE) | 1 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 4 | |
| 9X9614 | 24 TERMINAL (SINGLE) | 6 | |
| 9X9615 | 25 TERMINAL (SINGLE) | 7 | |
| 9X9616 | 26 COVER-END | 4 | |
| 9X9675 | 27 BRACKET-END | 4 | |
| 1057542 | 28 STRIP-CONTACT | 1 | |
| 1057543 | 29 BLOCK-FUSE | 5 | |
| 1057692 | 30 ISOLATOR | 34 | |
| 1057693 | 31 ISOLATOR | 3 | |
| 1061826 | 32 TERMINAL | 4 | |
| 1072701 | 33 STRIP-CONTACT | 1 | |
| 1096507 | 34 SWITCH AS-PUSH BUTTON | 1 | |
| 1096539 | 35 PLATE-SEPARATOR | 1 | |
| 1103891 | 36 COVER-END | 1 | |
| 1151322 | 37 TERMINAL (DOUBLE) | 102 | |
| 1152538 | 38 COVER-END | 5 | |
| 1152542 | 39 PLUG | 3 | |
| 1152945 | 40 KIT-MARKER | 1 | |
| 1165137 | 41 SPACER (TERMINAL) | 1 | |
| 1165193 | 42 COVER-END | 1 | |
| 1216159 | 43 MODULE-RELAY | 3 | |
| 1253903 | 44 PANEL AS | 1 | |
| 1220801 | 45 HARNESS AS-BOX | 1 | |
| 1S9593 | STRAP-CABLE | 9 | |
| 3S2093 | STRAP-CABLE | 5 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8T6342 | TUBE-HEAT SHRINK (3.2-MM DIA)(15-CM) | ||
| 9X6987 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 1093038 | END-WIRE (16-GA) | 24 | |
| 1093039 | END-WIRE (12-GA) | 4 | |
| 1108714 | END-WIRE (18-GA) | 7 | |
| 1127497 | END-WIRE (14-GA) | 16 | |
| 1217875 | ANGLE (4-CM) | ||
| 1216865 | END-WIRE | 4 | |
| 1220802 | 46 BOX AS-JUNCTION | 1 | |
| 1246116 | 47 CONTROL GP-ELECTRONIC | 1 | |
| 1256489 | 48 COVER-DUCT (188-CM) | ||
| 1256490 | 49 DUCT-WIRE (188-CM) | ||
| 1256491 | 50 COVER-DUCT (67-CM) | ||
| 1256492 | 51 DUCT-WIRE (66CM) | ||
| 1271574 | 52 STRIP-CONTACT | 1 | |
| 1271626 | 53 BLOCK-CONTACT | 1 | |
| 1280937 | 55 TERMINAL | 18 | |
| 1287375 | 56 CONTROL GP-ENGINE MONITORING | 1 | |
| 1422499 | 57 HARNESS AS-WIRING | 1 | |
| 1S9593 | STRAP-CABLE | 2 | |
| 3E5412 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 3S2093 | STRAP-CABLE | 13 | |
| 5P6009 | TUBE-HEAT SHRINK (9.52-MM DIA)(0.02-M) | ||
| 8L8413 | STRAP-CABLE (WHITE) | 4 | |
| 8T6342 | TUBE-HEAT SHRINK (3.2-MM DIA)(32-CM) | ||
| 1093038 | END-WIRE (16-GA) | 2 | |
| 1108714 | END-WIRE (18-GA) | 18 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 1093182 | 58 PLATE-SEPARATOR | 1 | |
| 1256489 | 59 COVER-DUCT (56-CM) | ||
| 1256490 | 60 DUCT-WIRE (56-CM) | ||
| 1256491 | 61 COVER-DUCT (25-CM) | ||
| 1256492 | 62 DUCT-WIRE (26-CM) | ||
| 1271682 | KIT-MARKER | 1 |
