System And Components
122-0803 BOX GP-JUNCTION (CHG -05 THRU -07, -07D1)Type 3
Group No: 122-0803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1615 | 1 BOLT (1/4-20X0.75-IN) | 3 | |
| 1B2714 | 2 BOLT (1/4-20X2.5-IN) | 2 | |
| 1S9593 | 3 STRAP-CABLE | 2 | |
| 2W6090 | 4 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 3E0105 | 5 MOUNT | 3 | |
| 2045569 | 6 BLOCK-TERMINAL | 7 | |
| 3E0357 | 7 DIODE AS | 1 | |
| 1748737 | 8 BAR-FIXED BRIDGE | 1 | |
| 3E3566 | 9 BRIDGE-INSERTION | 1 | |
| 9Y6027 | 10 FUSE-CERAMIC (10-AMPERE) | 5 | |
| 3T9377 | 11 RESISTOR | 1 | |
| 3V3308 | 12 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 4P4251 | 13 GASKET | 1 | |
| 5P0537 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 5S4246 | 15 LOCKWASHER | 4 | |
| 6B4540 | 16 NUT (4-40-THD) | 4 | |
| 7G0020 | 17 RESISTOR | 2 | |
| 7S1201 | 18 SCREW-MACHINE (8-32X0.375-IN) | 33 | |
| 8C8560 | 19 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 8D9537 | 20 CAP-DUST | 1 | |
| 8T1296 | 21 WASHER (10.5X19X3.5-MM THK) | 1 | |
| 8L8413 | 22 STRAP-CABLE (WHITE) | 1 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 4 | |
| 2255522 | 24 BLOCK-TERMINAL (800-VOLT, 41-AMPERE) | 6 | |
| 2045570 | 25 COVER-END | 1 | |
| 1972686 | 26 BRACKET | 3 | |
| 9X9616 | 27 COVER-END | 1 | |
| 3E0369 | 28 BRIDGE-INSERTION | 5 | |
| 1972690 | 29 BLOCK-FUSE | 5 | |
| 3E0368 | 30 STRIP-CONTACT | 6 | |
| 2381271 | 31 COVER-END | 2 | |
| 2381254 | 32 TERMINAL | 4 | |
| 2719106 | 33 COVER | 1 | |
| 1096507 | 34 SWITCH AS-PUSH BUTTON | 1 | |
| 2385375 | 35 COVER | 1 | |
| 1976948 | 36 BRIDGE | 2 | |
| 2627411 | 37 BLOCK-TERMINAL (600-VOLT, 30-AMPERE) | 103 | |
| 2638768 | 38 COVER | 5 | |
| 1152542 | 39 PLUG | 3 | |
| 2092142 | 40 KIT-MARKER | 1 | |
| 2287417 | 41 COVER | 1 | |
| 2719105 | 42 TERMINAL | 18 | |
| 1216159 | 43 MODULE-RELAY | 3 | |
| 1253903 | 44 PANEL AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 5 | |
| 1220801 | 45 HARNESS AS-BOX | 1 | |
| 1S9593 | STRAP-CABLE | 9 | |
| 3S2093 | STRAP-CABLE | 5 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9X6987 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 1220802 | 46 BOX AS-JUNCTION | 1 | |
| 1246116 | 47 CONTROL GP-ELECTRONIC | 1 | |
| 1256489 | 48 COVER-DUCT (188-CM) | ||
| 1256490 | 49 DUCT-WIRE (188-CM) | ||
| 1256491 | 50 COVER-DUCT (67-CM) | ||
| 1256492 | 51 DUCT-WIRE (66-CM) | ||
| 1976949 | 52 STRIP-CONTACT | 1 | |
| 1271626 | 53 BLOCK-CONTACT | 1 | |
| 1287375 | 55 CONTROL GP-ENGINE MONITORING | 1 | |
| 1422499 | 56 HARNESS AS-WIRING | 1 | |
| 1S9593 | STRAP-CABLE | 2 | |
| 3E5412 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 3S2093 | STRAP-CABLE | 13 | |
| 8L8413 | STRAP-CABLE (WHITE) | 4 | |
| 1256489 | 57 COVER-DUCT (56-CM) | ||
| 1256490 | 58 DUCT-WIRE (56-CM) | ||
| 1256491 | 59 COVER-DUCT (25-CM) | ||
| 1256492 | 60 DUCT-WIRE (26-CM) | ||
| 1798907 | 61 BLOCK-TERMINAL (400-VOLT, 16-AMPERE) | 2 | |
| 3E0356 | 62 BLOCK-TERMINAL | 2 | |
| 1057692 | 63 ISOLATOR | 22 | |
| 1057693 | 64 ISOLATOR | 3 | |
| 1271682 | KIT-MARKER | 1 |
