System And Components
129-6690 BOX GP-JUNCTION (CHG -00, -01)LH COMBUSTION BUFFER/DETONATION SENSOR
Group No: 129-6690
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6B4540 | 1 NUT (4-40-THD) | 8 | |
| 4P4251 | 2 GASKET | 2 | |
| 8L8413 | 3 STRAP-CABLE (WHITE) | 5 | |
| 1108714 | 4 END-WIRE (18-GA) | 9 | |
| 1057692 | 5 ISOLATOR | 18 | |
| 1296688 | 6 BOX AS | 1 | |
| 1267965 | 7 PLATE AS | 1 | |
| 0950742 | 8 SCREW-MACHINE (M6X1X16-MM) | 4 | |
| 1151322 | 9 TERMINAL (DOUBLE) | 30 | |
| 1152538 | 10 COVER-END | 2 | |
| 9X9675 | 11 BRACKET-END | 2 | |
| 1303944 | 12 TAG | 1 | |
| 3E0105 | 13 MOUNT | 5 | |
| 3E0369 | 14 BRIDGE-INSERTION | 2 | |
| 3E0368 | 15 STRIP-CONTACT | 6 | |
| 1179564 | 16 RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 9X0481 | 17 RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 8C8560 | 18 SCREW-LOCK (4-40X0.5-IN) | 8 | |
| 5S4246 | 19 LOCKWASHER | 8 | |
| 5P5677 | WIRE (18-GA, BLACK) | ||
| 1149034 | KIT-MARKER | 1 | |
| 1297278 | KIT-MARKER | 1 |
