System And Components
7C-4288 DRIVE GP-MAGNETO (CHG -00 THRU -06, -06D1)
Group No: 7C-4288
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1307645 | 1 HOUSING AS | 1 | |
| 8F6800 | 2 BUSHING-TERMINAL | 2 | |
| 9S4191 | 3 PLUG (9/16-18-THD) | 2 | |
| 6V5049 | SEAL-O-RING | 2 | |
| 1W8929 | 4 COUPLING | 1 | |
| 7E5486 | 5 GEAR (29-TEETH) | 1 | |
| 0S1571 | 6 BOLT (3/8-16X1.75-IN) | 1 | |
| 7E5485 | 7 GEAR (116-TEETH) | 1 | |
| 1A1460 | 8 BOLT (1/2-13X2-IN) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V5135 | 9 SETSCREW-SOCKET (7/16-20X0.375-IN) | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 4 | |
| 3V3308 | 11 WASHER-HARD (10.2X20.5X2.5-MM THK) | 8 | |
| 6V5060 | 12 SEAL-O-RING | 1 | |
| 8K4909 | 13 PLATE | 1 | |
| 7C7362 | 14 GASKET | 1 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 4 |
