Assembly
100%

231-4153 IGNITION GP-GAS ENGINE (CHG -00, -00D1)VARIABLE TIMING

Group No: 231-4153
Part NumberPart NameQty
0S05091 BOLT (3/8-16X0.75-IN)2
0S15712 BOLT (3/8-16X1.75-IN)1
0S15883 BOLT (3/8-16X1.25-IN)14
0S15944 BOLT (3/8-16X1-IN)14
0S16205 BOLT (1/2-13X0.75-IN)1
3P06506 SEAL-O-RING12
3V33087 WASHER-HARD (10.2X20.5X2.5-MM THK)35
4B33888 BOLT (5/16-18X1.125-IN)36
4P81349 CLIP (LADDER)1
4S196210 CLIP (LOOP)1
4S571911 SPACER (10.31X25X12.7-MM THK)1
5P602512 LOCKWIRE (3.6M)
5P824513 WASHER-HARD (13.5X25.5X3-MM THK)1
6V383014 SEAL-O-RING12
7E305615 HARNESS AS-WIRING (IGNITION)12
9D3955PLUG AS-CONNECTOR (3-PIN)1
7E836216 TUBE AS12
7H393717 LOCKWASHER1
7W437718 TRANSFORMER12
8S815819 SEAL-WIRE (3.6M)
8T189520 CLIP (SLOT)12
8T189621 CLIP (TAB)12
8T752922 CLIP1
9L913223 WASHER-HARD (10.2X25.5X2.5-MM THK)14
9M197424 WASHER-HARD (8.8X16X2-MM THK)36
9S875225 NUT-FULL (3/8-16-THD)16
9X677226 STRAP-CABLE1
109432827 BRACKET4
207450928 EXTENSION AS12
8L2777SEAL-O-RING1
1251372SEAL-O-RING1
129669129 BRACKET6
226381030 BRACKET1
146181531 STRAP AS1
160991232 SEAL-INTEGRAL12
227596733 CONTROL GP-IGNITION1
194851834 SPARK PLUG12
9Y6792GASKET-SPARK PLUG1
201071235 HARNESS AS-WIRING (IGNITION)1
1462590PLUG AS-CONNECTOR1
2A463936 BOLT (3/8-16X1.625-IN)2
226381137 BRACKET2
