System And Components
7C-0449 IGNITION GP-GAS ENGINE (CHG -00 THRU -07)VARIABLE TIMING
Group No: 7C-0449
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T1895 | 1 CLIP (SLOT) | 6 | |
| 8T1896 | CLIP (TAB) | 6 | |
| 5P7854 | 2 CLIP (LOOP) | 1 | |
| 7W4377 | 3 TRANSFORMER | 12 | |
| 7W5215 | GASKET | 12 | |
| 0S1618 | 4 BOLT (5/16-18X1-IN) | 36 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 36 | |
| 8F1801 | 5 U-BOLT | 2 | |
| 7E3056 | 6 HARNESS AS-WIRING (IGNITION) | 12 | |
| 9S8752 | 7 NUT-FULL (3/8-16-THD) | 4 | |
| 3P0650 | 8 SEAL-O-RING | 12 | |
| 7E8362 | 9 TUBE AS | 12 | |
| 6I0980 | 10 EXTENSION AS | 12 | |
| 6V3830 | 11 SEAL-O-RING | 12 | |
| 1064128 | 12 SPARK PLUG | 12 | |
| 0S1591 | 13 BOLT (3/8-16X1.5-IN) | 7 | |
| 4S1962 | 14 CLIP (LOOP) | 1 | |
| 7E1530 | 15 HARNESS AS | 1 | |
| 0S1590 | 16 BOLT (3/8-16X2-IN) | 3 | |
| 7E6215 | 17 MAGNETO GP | 1 | |
| 6V1196 | 18 SEAL-O-RING | 1 | |
| 8M9024 | 19 WASHER-HARD (10.2X22.5X5-MM THK) | 4 | |
| 4P8467 | 20 BOX AS-CONTROL | 1 | |
| 7W2264 | HARNESS AS | 1 | |
| 3V3308 | 21 WASHER-HARD (10.2X20.5X2.5-MM THK) | 14 | |
| 0S1621 | 22 BOLT (1/2-13X1-IN) | 1 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 2D7134 | 23 STRAP AS | 1 | |
| 7E3222 | 24 MOUNT-FLEXIBLE | 4 | |
| 9S8750 | 25 NUT-FULL (1/4-20-THD) | 8 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 7G1239 | 26 SPACER (10.5X19X4.5-MM THK) | 3 | |
| 8T7529 | 27 CLIP | 1 | |
| 7X6034 | 28 STRAP AS-GROUND | 1 | |
| 6N0905 | 29 SPACER (0.43X0.59X2.5-IN THK) | 4 | |
| 7E5721 | 30 PLATE AS | 1 | |
| 0S1608 | 31 BOLT (3/8-16X3.75-IN) | 4 | |
| 9Y6792 | GASKET-SPARK PLUG | 12 |
