System And Components
119-4715 VALVE GP-SOLENOID (CHG -01 THRU -03, -03D1, -04, -04D1)GAS SHUTOFF - LOW BTU
Group No: 119-4715
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 2 | |
| 1B2713 | 2 BOLT (1/4-20X1.75-IN) | 2 | |
| 3B6500 | 3 ELBOW | 2 | |
| 8M7145 | 4 WASHER (10.2X28.5X5-MM THK) | 4 | |
| 4K0367 | 5 NUT-FULL (5/8-11-THD) | 8 | |
| 4S6399 | 6 CONNECTOR | 1 | |
| 5P0537 | 7 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P8247 | 8 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 5R9705 | 9 GASKET | 2 | |
| 6V8002 | 10 SEAL-O-RING | 1 | |
| 7K9197 | 11 ELBOW | 4 | |
| 9L9132 | 12 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9S8750 | 13 NUT-FULL (1/4-20-THD) | 2 | |
| 9S8752 | 14 NUT-FULL (3/8-16-THD) | 4 | |
| 1296657 | 15 TUBE AS | 1 | |
| 9X8883 | 16 BOLT (5/8-11X2.75-IN) | 8 | |
| 0016449 | 17 CONNECTOR | 3 | |
| 1045693 | 18 ADAPTER AS | 1 | |
| 1228699 | 19 BRACKET AS | 1 | |
| 1229096 | 20 U-BOLT | 2 | |
| 1230825 | 21 VALVE GP-SOLENOID | 1 | |
| 1292588 | 22 VALVE-SHUTOFF (GAS) | 1 | |
| 1294036 | 23 ADAPTER AS | 1 | |
| 1294037 | 24 ADAPTER AS | 1 | |
| 1296656 | 25 TUBE AS | 1 |
