104-3715 WIRING GP-SENSOR (CHG -01 THRU -03)PART OF 109-5621 COMPONENT GP, 106-8117, 106-8119 SCHEMATIC & COMPONENT GP

Group No: 104-3715
Part NumberPart NameQty
1S09941 CLIP (LOOP)2
10718662 HARNESS AS-WIRING1
3V33083 WASHER-HARD (10.2X20.5X2.5-MM THK)1
5P92974 CLIP (LOOP)9
0S15885 BOLT (3/8-16X1.25-IN)3
10895286 CLIP (SLOT)5
10895297 CLIP (TAB)5
9L91328 WASHER-HARD (10.2X25.5X2.5-MM THK)5
8L84139 STRAP-CABLE (WHITE)3
112093110 HARNESS AS-WIRING1
3B19151 BOLT (3/8-16X1.375-IN)2
6K49342 CLIP (SLOT)5
6K49353 CLIP (TAB)5
10718674 HARNESS AS-WIRING1
10713495 PLATE AS1
10393976 CLAMP2
4P81347 CLIP (LADDER)1
9X67728 STRAP-CABLE1
3V33089 WASHER-HARD (10.2X20.5X2.5-MM THK)6
5P929710 CLIP (LOOP)1
0S050911 BOLT (3/8-16X0.75-IN)4
0S158812 BOLT (3/8-16X1.25-IN)5
9L913213 WASHER-HARD (10.2X25.5X2.5-MM THK)5
112092014 HARNESS AS-WIRING1
110519415 END-WIRE (14-GA)24
110519316 END-WIRE (16-GA)84
109303917 END-WIRE (12-GA)6
9X67721 STRAP-CABLE1
10718652 HARNESS AS-WIRING1
7C20683 BRACKET1
0L13514 BOLT (3/8-16X0.875-IN)1
3V33085 WASHER-HARD (10.2X20.5X2.5-MM THK)12
9S87526 NUT-FULL (3/8-16-THD)5
5P78547 CLIP (LOOP)1
5P92978 CLIP (LOOP)8
0S16159 BOLT (1/4-20X0.75-IN)4
5P0537WASHER-HARD (7.2X14.5X2-MM THK)4
7K570710 U-BOLT2
7E295511 BRACKET AS1
0S050912 BOLT (3/8-16X0.75-IN)4
0S158813 BOLT (3/8-16X1.25-IN)1
7E295614 BRACKET AS1
108952815 CLIP (SLOT)2
1089529CLIP (TAB)2
112091916 HARNESS AS-WIRING1
0S159417 BOLT (3/8-16X1-IN)2
9L913218 WASHER-HARD (10.2X25.5X2.5-MM THK)2
1S959319 STRAP-CABLE2
8L841320 STRAP-CABLE (WHITE)1
4P758121 CLIP (LADDER)1
