System And Components
148-7632 LINES GP-HYDRAULIC (CHG -04, -05)HYDRAC-DISCHARGE
Group No: 148-7632
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P6814 | 1 MANIFOLD | 1 | |
| 7G4326 | 2 PLATE | 1 | |
| 8C0569 | 3 TEE-O-RING | 2 | |
| 8C5053 | 4 ADAPTER | 1 | |
| 9C5344 | 5 SPACER (10.5X20X18-MM THK) | 2 | |
| 1216750 | 6 MANIFOLD | 1 | |
| 1263005 | 7 PIPE | 4 | |
| 1386144 | 8 FILTER GP-ENGINE OIL | 1 | |
| 1386158 | 9 VALVE-CHECK | 1 | |
| 1487605 | 10 TUBE AS | 1 | |
| 1487606 | 11 TUBE AS | 1 | |
| 1487607 | 12 TUBE AS | 1 | |
| 1487608 | 13 TUBE AS | 1 | |
| 1487609 | 14 TUBE AS | 1 | |
| 1487610 | 15 TUBE AS | 1 | |
| 1487611 | 16 TUBE AS | 1 | |
| 1487612 | 17 TUBE AS | 1 | |
| 1487613 | 18 TUBE AS | 1 | |
| 1487614 | 19 TUBE AS | 1 | |
| 1487615 | 20 TUBE AS | 1 | |
| 1487616 | 21 TUBE AS | 1 | |
| 1487617 | 22 TUBE AS | 1 | |
| 1487618 | 23 TUBE AS | 1 | |
| 1487619 | 24 TUBE AS | 1 | |
| 1487621 | 25 BRACKET AS | 1 | |
| 1487622 | 26 BRACKET AS | 2 | |
| 1487623 | 27 BRACKET | 2 | |
| 1487625 | 28 BRACKET AS | 1 | |
| 1487626 | 29 BRACKET | 1 | |
| 1487627 | 30 CLAMP | 2 | |
| 1487628 | 31 CLAMP | 2 | |
| 1487630 | 32 BRACKET | 1 | |
| 1487631 | 33 PLATE | 1 | |
| 1487635 | 34 MANIFOLD | 1 | |
| 1582940 | 35 HOSE AS | 1 | |
| 1700990 | 36 CLAMP | 2 | |
| 1763586 | 37 VALVE AS-RELIEF | 1 | |
| 2M9780 | SEAL-O-RING | 2 | |
| 1763592 | 38 BRACKET | 2 | |
| 1987779 | 39 BRACKET AS | 1 | |
| 1993141 | 40 ACCUMULATOR GP-TURBOCHARGER | 1 | |
| 0L1143 | 41 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1352 | 42 BOLT (3/8-16X3.25-IN) | 2 | |
| 0L2070 | 43 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1571 | 44 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 45 BOLT (3/8-16X1.25-IN) | 15 | |
| 0S1590 | 46 BOLT (3/8-16X2-IN) | 4 | |
| 0S1591 | 47 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 48 BOLT (3/8-16X1-IN) | 15 | |
| 0S1608 | 49 BOLT (3/8-16X3.75-IN) | 4 | |
| 1A1460 | 50 BOLT (1/2-13X2-IN) | 2 | |
| 1A2029 | 51 BOLT (3/8-16X1.125-IN) | 6 | |
| 1A5183 | 52 BOLT (3/8-16X4.75-IN) | 1 | |
| 2M9780 | 53 SEAL-O-RING | 7 | |
| 3D2824 | 54 SEAL-O-RING | 12 | |
| 3J1907 | 55 SEAL-O-RING | 11 | |
| 3K0360 | 56 SEAL-O-RING | 1 | |
| 3V3308 | 57 WASHER-HARD (10.2X20.5X2.5-MM THK) | 81 | |
| 5K9660 | 58 CLIP (LOOP) | 7 | |
| 5P8245 | 59 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V8398 | 60 SEAL-O-RING | 12 | |
| 6V8629 | 61 ELBOW | 1 | |
| 6V8637 | 62 CONNECTOR | 6 | |
| 6V8638 | 63 CONNECTOR | 3 | |
| 6V8640 | 64 CONNECTOR | 2 | |
| 6V8721 | 65 ELBOW | 1 | |
| 6V8733 | 66 UNION | 3 | |
| 6V8784 | 67 TEE-FACE SEAL | 1 | |
| 6V9004 | 68 ELBOW | 1 | |
| 6V9007 | 69 ELBOW | 1 | |
| 6V9182 | 70 ELBOW | 1 | |
| 6V9746 | 71 SEAL-O-RING | 21 | |
| 6V9873 | 72 CONNECTOR | 5 | |
| 7M8485 | 73 SEAL-O-RING | 1 | |
| 8T1885 | 74 CLIP (SLOT) | 2 | |
| 8T1886 | 75 CLIP (TAB) | 2 | |
| 8T6451 | 76 ELBOW | 1 | |
| 8T6876 | 77 ELBOW | 3 | |
| 9S4185 | 78 PLUG (3/4-16-THD) | 1 | |
| 9S4191 | 79 PLUG (9/16-18-THD) | 3 | |
| 9S8752 | 80 NUT-FULL (3/8-16-THD) | 27 |
