Assembly
100%

115-9818 SUPPORT GP-ACCESSORY MODULE -ACCESSORY (CHG -00, -00D1)

Group No: 115-9818
Part NumberPart NameQty
2H38881 SETSCREW-SQUARE HEAD (1/2-13-THD)4
5P82452 WASHER-HARD (13.5X25.5X3-MM THK)68
1F7958NUT-FULL (1/2-13-THD)40
0S1587BOLT (1/2-13X1.75-IN)40
11553023 BRACKET AS4
11553034 SUPPORT AS2
11553055 SUPPORT AS2
11553066 PLATE4
1D46127 BOLT (3/4-10X4-IN)16
5P8248WASHER-HARD (20X36.5X3.5-MM THK)32
2J3506NUT-FULL (3/4-10-THD)16
11648928 PLATE4
2W70309 BAR16
115564010 ANGLE4
115764911 CHANNEL AS2
116489312 SHIM20
4B361913 SETSCREW-SQUARE HEAD (5/8-11-THD)4
