System And Components
104-4836 PISTON & ROD GP (CHG -00 THRU -04)11:1 RATIO
Group No: 104-4836
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1503002 | 1 PISTON AS | 1 | |
| 1293990 | 2 PIN-PISTON | 1 | |
| 7C1413 | 3 RETAINER-PIN | 2 | |
| 1515207 | 4 ROD AS-CONNECTING | 1 | |
| 4P6143 | 5 BUSHING | 1 | |
| 6V9801 | 6 NUT-12 POINT (3/4-16-THD) | 4 | |
| 1W0098 | 7 BOLT-CONNECTING ROD (3/4-16X12.87-IN) | 4 | |
| 4W8344 | 8 RETAINER | 2 | |
| 1014181 | 9 BEARING-CONNECTING ROD | 1 | |
| 7E2614 | BEARING-CONNECTING ROD (1-MM US) | 1 | |
| 7E2615 | BEARING-CONNECTING ROD (0.5-MM US) | 1 | |
| 7E8215 | 10 RING-PISTON (TOP) | 1 | |
| 7C7886 | 11 RING-PISTON (INTERMEDIATE) | 1 | |
| 4P8958 | 12 RING-PISTON (OIL CONTROL) | 1 |
