System And Components
117-4911 PRECHAMBER GP (CHG -00 THRU -02)LANDFILL
Group No: 117-4911
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1171144 | 1 BODY-PRECHAMBER | 1 | |
| 1143365 | 2 PRECHAMBER AS | 1 | |
| 1084842 | 3 GASKET | 1 | |
| 1084844 | 4 GASKET | 1 | |
| 5P4889 | 5 SEAL-O-RING | 1 | |
| 6V1179 | 6 SEAL-O-RING | 1 | |
| 6J2244 | 7 SEAL-O-RING | 1 | |
| 6V4368 | 8 SEAL-O-RING | 1 | |
| 1229453 | 9 VALVE AS-CHECK | 1 | |
| 7E1629 | BODY-CHECK VALVE | 1 | |
| 6I1316 | 10 RETAINER-VALVE | 1 | |
| 9M5590 | 11 BALL | 1 | |
| 8K2090 | 12 TUBE | 2 | |
| 7E1630 | 13 GASKET | 1 | |
| 3V3308 | 14 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 3P0647 | 15 SEAL-O-RING | 1 | |
| 1171145 | 16 FLANGE | 1 | |
| 1171866 | 17 COVER | 1 | |
| 5E8767 | 18 SEAL-O-RING | 1 | |
| 7M8485 | 19 SEAL-O-RING | 1 | |
| 8B2377 | 20 BOLT (1/4-20X2-IN) | 4 | |
| 5P0537 | 21 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 7N2043 | 22 DOWEL | 1 | |
| 9S9334 | 23 PLUG (1-5/16-12-THD) | 1 | |
| 2M8138 | 24 BOLT (3/8-16X5.25-IN) | 2 |
