System And Components
119-5005 LINES GP-WATER (CHG -02 THRU -05)TWO STAGE AFTERCOOLER
Group No: 119-5005
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P9224 | 1 COVER | 1 | |
| 5R9779 | 2 GASKET | 4 | |
| 7W3269 | 3 GASKET | 5 | |
| 7W3271 | 4 COVER | 1 | |
| 7W6092 | 5 HOUSING | 1 | |
| 7W6998 | 6 ORIFICE | 1 | |
| 8T6765 | 7 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1112556 | 8 GASKET | 1 | |
| 1195012 | 9 TUBE AS | 1 | |
| 1282820 | 10 TUBE AS | 1 | |
| 1503811 | 11 TUBE AS | 1 | |
| 2224708 | 12 BELLOWS AS | 1 | |
| 2283634 | 13 COVER | 1 | |
| 0S1588 | 15 BOLT (3/8-16X1.25-IN) | 12 | |
| 0S1589 | 16 BOLT (5/8-11X1.75-IN) | 8 | |
| 0S1590 | 17 BOLT (3/8-16X2-IN) | 1 | |
| 0S1594 | 18 BOLT (3/8-16X1-IN) | 10 | |
| 3V3308 | 19 WASHER-HARD (10.2X20.5X2.5-MM THK) | 29 | |
| 4B4043 | 20 BOLT (5/8-11X1.375-IN) | 8 | |
| 4K0367 | 21 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8247 | 22 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 6V5504 | 23 SEAL-O-RING | 2 | |
| 8M9024 | 24 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 8T6762 | 25 PLUG-PIPE (1/2-14-THD) | 5 | |
| 9S8752 | 26 NUT-FULL (3/8-16-THD) | 5 | |
| 9X2646 | 27 CLIP (SLOT) | 1 | |
| 9X2647 | 28 CLIP (TAB) | 1 | |
| 9X8882 | 29 BOLT (5/8-11X2.5-IN) | 8 |
