System And Components
140-1123 LINES GP-WATER (CHG -00, -01)TWO STAGE AFTERCOOLER-OIL COOLER
Group No: 140-1123
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A2161 | 1 SPACER (0.4X0.875X0.381-IN) | 1 | |
| 2N1117 | 2 CLIP | 2 | |
| 4B4043 | 3 BOLT (5/8-11X1.375-IN) | 4 | |
| 0S1589 | 4 BOLT (5/8-11X1.75-IN) | 12 | |
| 5R9779 | 5 GASKET | 4 | |
| 9X8882 | 6 BOLT (5/8-11X2.5-IN) | 8 | |
| 1074862 | 7 PLATE | 2 | |
| 1100096 | 8 RING | 1 | |
| 1112556 | 9 GASKET | 1 | |
| 1191571 | 10 TUBE AS | 1 | |
| 1221148 | 11 CLAMP AS | 2 | |
| 1282817 | 12 TUBE AS | 1 | |
| 1282820 | 13 TUBE AS | 1 | |
| 1282840 | 14 BRACKET AS | 1 | |
| 1409703 | 15 TUBE AS | 1 | |
| 1409704 | 16 TUBE AS | 1 | |
| 1409707 | 17 BRACKET AS | 1 | |
| 0S1571 | 18 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 19 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1590 | 20 BOLT (3/8-16X2-IN) | 1 | |
| 0S1591 | 21 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 2 | |
| 3B1915 | 23 BOLT (3/8-16X1.375-IN) | 1 | |
| 3V3308 | 24 WASHER-HARD (10.2X20.5X2.5-MM THK) | 26 | |
| 4K0367 | 25 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8247 | 26 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 6V5066 | 27 SEAL-O-RING | 2 | |
| 8T6762 | 28 PLUG-PIPE (1/2-14-THD) | 8 | |
| 9S8752 | 29 NUT-FULL (3/8-16-THD) | 11 | |
| 9X2646 | 30 CLIP (SLOT) | 1 | |
| 9X2647 | 31 CLIP (TAB) | 1 |
