System And Components
140-1123 LINES GP-WATER (CHG -02, -03-03D1 THRU -05)TWO STAGE AFTERCOOLER-OIL COOLER
Group No: 140-1123
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A2161 | 1 SPACER (0.4X0.875X0.381-IN) | 1 | |
| 2N1117 | 2 CLIP | 2 | |
| 4P9224 | 3 COVER | 1 | |
| 5R9779 | 4 GASKET | 4 | |
| 7W3269 | 5 GASKET | 5 | |
| 7W3271 | 6 COVER | 1 | |
| 7W6092 | 7 HOUSING | 1 | |
| 7W6998 | 8 ORIFICE | 1 | |
| 8T6765 | 9 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1074862 | 10 PLATE | 2 | |
| 1100096 | 11 RING | 1 | |
| 1112556 | 12 GASKET | 3 | |
| 1221148 | 13 CLAMP AS | 2 | |
| 1282817 | 14 TUBE AS | 1 | |
| 1282820 | 15 TUBE AS | 1 | |
| 1282840 | 16 BRACKET AS | 1 | |
| 1409703 | 17 TUBE AS | 1 | |
| 1409704 | 18 TUBE AS | 1 | |
| 1409707 | 19 BRACKET AS | 1 | |
| 1503811 | 20 TUBE AS | 1 | |
| 2224708 | 21 BELLOWS AS | 1 | |
| 2283634 | 22 COVER | 2 | |
| 0L1351 | 23 BOLT (3/8-16X0.875-IN) | 4 | |
| 0S1571 | 24 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 25 BOLT (3/8-16X1.25-IN) | 13 | |
| 0S1589 | 26 BOLT (5/8-11X1.75-IN) | 12 | |
| 0S1590 | 27 BOLT (3/8-16X2-IN) | 1 | |
| 0S1591 | 28 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 29 BOLT (3/8-16X1-IN) | 8 | |
| 3B1915 | 30 BOLT (3/8-16X1.375-IN) | 1 | |
| 3V3308 | 31 WASHER-HARD (10.2X20.5X2.5-MM THK) | 52 | |
| 4B4043 | 32 BOLT (5/8-11X1.375-IN) | 4 | |
| 4K0367 | 33 NUT-FULL (5/8-11-THD) | 24 | |
| 5P8247 | 34 WASHER-HARD (17X32X3.5-MM THK) | 64 | |
| 6V3250 | 35 SEAL-O-RING | 1 | |
| 6V5066 | 36 SEAL-O-RING | 1 | |
| 6V5504 | 37 SEAL-O-RING | 2 | |
| 8T6762 | 38 PLUG-PIPE (1/2-14-THD) | 9 | |
| 9S4191 | 39 PLUG (9/16-18-THD) | 1 | |
| 9S8752 | 40 NUT-FULL (3/8-16-THD) | 15 | |
| 9X2646 | 41 CLIP (SLOT) | 1 | |
| 9X2647 | 42 CLIP (TAB) | 1 | |
| 9X8882 | 43 BOLT (5/8-11X2.5-IN) | 24 |
