System And Components
141-3291 LINES GP-WATER (CHG -00, -01)TWO STAGE AFTERCOOLER
Group No: 141-3291
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A2161 | 1 SPACER (0.4X0.875X0.381-IN) | 2 | |
| 1W4059 | 2 COVER | 1 | |
| 2N1117 | 3 CLIP | 3 | |
| 4H4033 | 4 BOLT (5/8-18X1.375-IN) | 4 | |
| 0S1589 | 5 BOLT (5/8-11X1.75-IN) | 12 | |
| 5R9779 | 6 GASKET | 4 | |
| 1074862 | 7 PLATE | 3 | |
| 1282817 | 8 TUBE AS | 1 | |
| 1282818 | 9 TUBE AS | 1 | |
| 1282820 | 10 TUBE AS | 1 | |
| 1282840 | 11 BRACKET AS | 1 | |
| 1409704 | 12 TUBE AS | 1 | |
| 1409707 | 13 BRACKET AS | 1 | |
| 0S1571 | 14 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 15 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1590 | 16 BOLT (3/8-16X2-IN) | 1 | |
| 0S1591 | 17 BOLT (3/8-16X1.5-IN) | 4 | |
| 3B1915 | 18 BOLT (3/8-16X1.375-IN) | 1 | |
| 3V3308 | 19 WASHER-HARD (10.2X20.5X2.5-MM THK) | 20 | |
| 5P8247 | 20 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 6V5504 | 21 SEAL-O-RING | 1 | |
| 8T6762 | 22 PLUG-PIPE (1/2-14-THD) | 8 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 10 | |
| 9X2646 | 24 CLIP (SLOT) | 1 | |
| 9X2647 | 25 CLIP (TAB) | 1 |
