System And Components
150-3432 LINES GP-WATER (CHG -00)
Group No: 150-3432
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N1117 | 1 CLIP | 2 | |
| 5B0841 | 2 BOLT (5/8-18X1.75-IN) | 16 | |
| 5R9779 | 3 GASKET | 4 | |
| 1282840 | 4 BRACKET AS | 1 | |
| 1503429 | 5 TUBE AS | 1 | |
| 1503431 | 6 TUBE AS | 1 | |
| 1503430 | 7 TUBE AS | 1 | |
| 1347430 | 8 TUBE AS | 1 | |
| 0S1590 | 9 BOLT (3/8-16X2-IN) | 1 | |
| 0S1591 | 10 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1571 | 11 BOLT (3/8-16X1.75-IN) | 4 | |
| 3B1915 | 12 BOLT (3/8-16X1.375-IN) | 1 | |
| 3V3308 | 13 WASHER-HARD (10.2X20.5X2.5-MM THK) | 16 | |
| 5P8247 | 14 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 6V5066 | 15 SEAL-O-RING | 1 | |
| 8T6762 | 16 PLUG-PIPE (1/2-14-THD) | 7 | |
| 9S8752 | 17 NUT-FULL (3/8-16-THD) | 8 | |
| 9X2646 | 18 CLIP (SLOT) | 1 | |
| 9X2647 | 19 CLIP (TAB) | 1 | |
| 1A2161 | 20 SPACER (0.4X0.875X0.381-IN) | 4 | |
| 1074862 | 21 PLATE | 2 |
