System And Components
153-2788 CONTROL GP-FUEL -GAS (CHG -00, -01)Type 1
Group No: 153-2788
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L2341 | 1 NUT (1-1/2-12-THD)(SPL) | 1 | |
| 1S3584 | 2 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 3S2713 | 3 NUT-FULL (3/8-24-THD) | 2 | |
| 4D8532 | 4 LEVER | 1 | |
| 4E2250 | 5 HOUSING | 1 | |
| 4P0391 | 6 ROD | 1 | |
| 5H2532 | 7 KEY-WOODRUFF | 2 | |
| 5L3291 | 8 BEARING AS-BALL | 2 | |
| 6D3025 | 9 BALL BEARING | 2 | |
| 9X8887 | 10 BOLT (3/4-10X3-IN) | 4 | |
| 7C1178 | 11 CLEVIS | 2 | |
| 8M2337 | 12 WASHER (7.2X24.5X3-MM THK) | 6 | |
| 8C5607 | 13 MOUNT-ISOLATION | 6 | |
| 8C5608 | 14 SPACER (6.5X9.5X25.4-MM THK) | 3 | |
| 8C7315 | 15 ROD END | 1 | |
| 8C7321 | 16 ROD END | 2 | |
| 8T8207 | 17 ROD END | 1 | |
| 9U3300 | 18 SPACER (7X25X50-MM THK) | 3 | |
| 1073576 | 19 ACTUATOR GP-ELECTRONIC | 1 | |
| 1157768 | 20 LEVER | 1 | |
| 1186662 | 21 BRACKET AS | 1 | |
| 1186663 | 22 BRACKET AS | 1 | |
| 1186664 | 23 BRACKET AS | 1 | |
| 1186665 | 24 SHAFT | 1 | |
| 1271573 | 25 SHAFT | 1 | |
| 1282354 | 26 COUPLING | 1 | |
| 1413012 | 27 GUARD AS | 2 | |
| 1413013 | 28 POINTER | 1 | |
| 1487629 | 29 BRACKET | 2 | |
| 0S1571 | 30 BOLT (3/8-16X1.75-IN) | 3 | |
| 9S8752 | 31 NUT-FULL (3/8-16-THD) | 13 | |
| 0S1590 | 32 BOLT (3/8-16X2-IN) | 6 | |
| 0S1591 | 33 BOLT (3/8-16X1.5-IN) | 4 | |
| 2H3429 | 34 RING-RETAINING | 1 | |
| 2L6726 | 35 RING-RETAINING | 1 | |
| 9M1974 | 36 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 5P8248 | 37 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 6V3940 | 38 BOLT (M8X1.25X25-MM) | 4 | |
| 8M9024 | 39 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 8F6302 | 40 BOLT (1/4-20X3.75-IN) | 3 | |
| 0S1588 | 41 BOLT (3/8-16X1.25-IN) | 4 | |
| 1W3557 | 42 GASKET | 1 | |
| 7E1630 | 43 GASKET | 1 |
