Assembly
100%

156-0268 CONTROL GP-FUEL (CHG -00 THRU -04)GAS

Group No: 156-0268
Part NumberPart NameQty
1S35841 NUT-FULL (3/8-24 LH-THD)2
1W35572 GASKET1
3S27133 NUT-FULL (3/8-24-THD)2
4D85324 LEVER1
4E22505 HOUSING1
4P03916 ROD1
5H25327 KEY-WOODRUFF2
5L32918 BEARING AS-BALL2
6D30259 BALL BEARING2
7C117810 CLEVIS2
7E163011 GASKET1
8C560712 MOUNT-ISOLATION6
8C560813 SPACER (6.5X9.5X25.4-MM THK)3
8C697114 ROD END1
8C731515 ROD END1
8C732116 ROD END2
8H339017 NUT-FULL (1-1/2-12-THD)1
9U330018 SPACER (7X25X50-MM THK)3
107357619 ACTUATOR GP-ELECTRONIC1
115776820 LEVER1
118666221 BRACKET AS1
118666322 BRACKET AS1
118666423 BRACKET AS1
118666524 SHAFT1
127157325 SHAFT1
128120426 VALVE GP-GAS CONTROL1
128120527 TUBE AS1
141301228 GUARD AS2
141301329 POINTER1
176357230 COUPLING GP-SHAFT1
033603131 SEAL-O-RING1
0S157132 BOLT (3/8-16X1.75-IN)3
0S158833 BOLT (3/8-16X1.25-IN)12
0S159034 BOLT (3/8-16X2-IN)6
0S159135 BOLT (3/8-16X1.5-IN)4
1F795836 NUT-FULL (1/2-13-THD)4
2H342937 RING-RETAINING1
2L672638 RING-RETAINING1
3V330839 WASHER-HARD (10.2X20.5X2.5-MM THK)38
5P824540 WASHER-HARD (13.5X25.5X3-MM THK)8
5P824841 WASHER-HARD (20X36.5X3.5-MM THK)4
6V394042 BOLT (M8X1.25X25-MM)4
6V800243 SEAL-O-RING1
8F630244 BOLT (1/4-20X3.75-IN)3
8M233745 WASHER (7.2X24.5X3-MM THK)6
8M902446 WASHER-HARD (10.2X22.5X5-MM THK)2
9M197447 WASHER-HARD (8.8X16X2-MM THK)4
9S875248 NUT-FULL (3/8-16-THD)13
9X887349 BOLT (1/2-13X2.25-IN)4
9X888750 BOLT (3/4-10X3-IN)4
4P6945KIT-VALVE REPAIR1
4P6542KIT-VALVE GASKET1
4P6543KIT-VALVE SEAL1
