Assembly
100%

156-5322 CONTROL GP-FUEL (CHG -00 THRU -04)GAS - LOW BTU

Group No: 156-5322
Part NumberPart NameQty
1S35841 NUT-FULL (3/8-24 LH-THD)2
1W35572 GASKET1
3S27133 NUT-FULL (3/8-24-THD)1
4E22504 HOUSING1
4P03915 ROD1
5H25326 KEY-WOODRUFF2
5L32917 BEARING AS-BALL2
6D30258 BALL BEARING2
6I25209 LEVER2
7C117810 CLEVIS1
7E163011 GASKET1
7X337412 NUT-FULL (1/2-20-THD)1
8C560713 MOUNT-ISOLATION6
8C560814 SPACER (6.5X9.5X25.4-MM THK)3
8C697115 ROD END1
8C731516 ROD END1
8C732117 ROD END2
8H339018 NUT-FULL (1-1/2-12-THD)1
9U330019 SPACER (7X25X50-MM THK)3
107357620 ACTUATOR GP-ELECTRONIC1
118666321 BRACKET AS1
118666422 BRACKET AS1
119794423 TUBE AS1
127157324 SHAFT1
141301225 GUARD AS2
141301326 POINTER1
156026927 CLEVIS1
156027028 VALVE GP-GAS CONTROL1
156532029 BRACKET AS1
156532130 SHAFT1
176357231 COUPLING GP-SHAFT1
0S157132 BOLT (3/8-16X1.75-IN)4
0S158833 BOLT (3/8-16X1.25-IN)13
0S159034 BOLT (3/8-16X2-IN)6
0S159135 BOLT (3/8-16X1.5-IN)4
2H342936 RING-RETAINING1
2L672637 RING-RETAINING1
3V330838 WASHER-HARD (10.2X20.5X2.5-MM THK)43
4K036739 NUT-FULL (5/8-11-THD)8
5P824740 WASHER-HARD (17X32X3.5-MM THK)16
5P824841 WASHER-HARD (20X36.5X3.5-MM THK)4
6V394042 BOLT (M8X1.25X25-MM)2
6V800243 SEAL-O-RING2
8F630244 BOLT (1/4-20X3.75-IN)3
8M233745 WASHER (7.2X24.5X3-MM THK)6
8M902446 WASHER-HARD (10.2X22.5X5-MM THK)2
9M197447 WASHER-HARD (8.8X16X2-MM THK)2
9S875248 NUT-FULL (3/8-16-THD)16
9X888349 BOLT (5/8-11X2.75-IN)8
9X888750 BOLT (3/4-10X3-IN)4
1198266KIT-VALVE GASKET1
1198267KIT-VALVE SEAL1
1198268KIT-VALVE REPAIR1
