System And Components
125-3877 BOX GP-JUNCTION (CHG -00, -01)PART OF 125-3875 WIRING GP-ENGINE
Group No: 125-3877
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6B4540 | 1 NUT (4-40-THD) | 8 | |
| 1303944 | 2 TAG | 1 | |
| 4P4251 | 3 GASKET | 2 | |
| 8L8413 | 4 STRAP-CABLE (WHITE) | 5 | |
| 1108714 | 5 END-WIRE (18-GA) | 8 | |
| 1057692 | 6 ISOLATOR | 24 | |
| 1267964 | 7 BOX AS | 1 | |
| 1267965 | 8 PLATE AS | 1 | |
| 0950742 | 9 SCREW-MACHINE (M6X1X16-MM) | 4 | |
| 1151322 | 10 TERMINAL (DOUBLE) | 36 | |
| 1152538 | 11 COVER-END | 2 | |
| 9X9675 | 12 BRACKET-END | 2 | |
| 1149035 | 13 KIT-MARKER | 1 | |
| 3E0105 | 14 MOUNT | 5 | |
| 3E0369 | 15 BRIDGE-INSERTION | 3 | |
| 3E0368 | 16 STRIP-CONTACT | 7 | |
| 1179564 | 17 RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 9X0481 | 18 RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 8C8560 | 19 SCREW-LOCK (4-40X0.5-IN) | 8 | |
| 5S4246 | 20 LOCKWASHER | 8 | |
| 5P5677 | WIRE (18-GA, BLACK) | ||
| 1315514 | KIT-MARKER | 1 |
