System And Components
146-4290 IGNITION GP-GAS ENGINE (CHG -03, -04)VARIABLE TIMING
Group No: 146-4290
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S0509 | 1 BOLT (3/8-16X0.75-IN) | 2 | |
| 0S1571 | 2 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 3 BOLT (3/8-16X1.25-IN) | 16 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 18 | |
| 4B3388 | 5 BOLT (5/16-18X1.125-IN) | 48 | |
| 0S1620 | 6 BOLT (1/2-13X0.75-IN) | 1 | |
| 8T1896 | 7 CLIP (TAB) | 16 | |
| 1094328 | 8 BRACKET | 4 | |
| 1296691 | 9 BRACKET | 10 | |
| 4P8134 | 10 CLIP (LADDER) | 1 | |
| 4S1962 | 11 CLIP (LOOP) | 1 | |
| 8T7529 | 12 CLIP | 1 | |
| 1720063 | 13 CONTROL GP-MONITOR (CIS PROGRAMMING) | 1 | |
| 8T1895 | 14 CLIP (SLOT) | 16 | |
| 1461803 | 15 HARNESS AS-WIRING | 1 | |
| 1238641 | 16 EXTENSION AS | 16 | |
| 7E3056 | 17 HARNESS AS-WIRING (IGNITION) | 16 | |
| 7H3937 | 18 LOCKWASHER | 1 | |
| 9S8752 | 19 NUT-FULL (3/8-16-THD) | 16 | |
| 1458462 | 20 PLATE | 1 | |
| 1499931 | 21 SPARK PLUG | 16 | |
| 3P0650 | 22 SEAL-O-RING | 16 | |
| 6V3830 | 23 SEAL-O-RING | 16 | |
| 4S5719 | 24 SPACER (10.31X25X12.7-MM THK) | 1 | |
| 9X6772 | 25 STRAP-CABLE | 1 | |
| 1461815 | 26 STRAP AS | 1 | |
| 7W4377 | 27 TRANSFORMER | 16 | |
| 7E8362 | 28 TUBE AS | 16 | |
| 3V3308 | 29 WASHER-HARD (10.2X20.5X2.5-MM THK) | 35 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 9L9132 | 31 WASHER-HARD (10.2X25.5X2.5-MM THK) | 18 | |
| 9M1974 | 32 WASHER-HARD (8.8X16X2-MM THK) | 48 | |
| 5P6025 | 33 LOCKWIRE (4.9M) | ||
| 8S8158 | 34 SEAL-WIRE | 49 | |
| 1609912 | 35 SEAL-INTEGRAL | 16 | |
| 9Y6792 | GASKET-SPARK PLUG | 16 |
