125-3875 WIRING GP-ENGINE (CHG -02)PART OF 117-5308 SCHEMATIC & COMPONENT GP

Group No: 125-3875
Part NumberPart NameQty
5P82471 WASHER-HARD (17X32X3.5-MM THK)2
4N33292 WASHER (16.25X25.65X0.79-MM)1
8L41713 SENSOR GP-SPEED (ENGINE)2
10726754 SENSOR AS-SPEED (ENGINE SPEED)1
10930385 END-WIRE (16-GA)9
11087146 END-WIRE (18-GA)84
12578757 TUBE-HEAT SHRINK (7.44-MM DIA)
8T63428 TUBE-HEAT SHRINK (3.2-MM DIA)
10930399 END-WIRE (12-GA)6
5P929710 CLIP (LOOP)1
0L207011 BOLT (3/8-16X2.25-IN)4
091903512 SPACER (11X25X20-MM THK)4
7X104313 SENSOR GP-TEMPERATURE1
8T328514 ADAPTER1
6K817915 CLIP16
8T189516 CLIP (SLOT)14
8T189617 CLIP (TAB)14
124963318 CLIP (SLOT)6
9L913219 WASHER-HARD (10.2X25.5X2.5-MM THK)14
1B497120 SPACER (0.406X1X1-IN THK)14
0T057321 BOLT (3/8-16X2.75-IN)14
125385422 HARNESS AS1
125385623 HARNESS AS1
125385124 HARNESS AS1
9X677225 STRAP-CABLE9
3V330826 WASHER-HARD (10.2X20.5X2.5-MM THK)25
4P813427 CLIP (LADDER)3
9X677228 STRAP-CABLE5
107714229 SENSOR GP-PRESSURE (ENGINE OIL)1
6V864730 CONNECTOR1
6V504831 SEAL-O-RING3
6V504932 SEAL-O-RING5
114226933 SENSOR GP-TEMPERATURE (ENGINE OIL)1
100787034 ADAPTER-O-RING1
8L278635 SEAL-O-RING1
5P824536 WASHER-HARD (13.5X25.5X3-MM THK)1
5N284037 CLIP2
107395238 SENSOR GP-PRESSURE2
6V987239 CONNECTOR2
8T078840 ELBOW2
8L277941 SEAL-O-RING2
5B263842 BOLT (3/8-16X5.25-IN)1
4P758143 CLIP (LADDER)2
106915444 INSULATOR2
125458845 PLATE2
112927346 SENSOR GP-DETONATION (DETONATION)2
0S158747 BOLT (1/2-13X1.75-IN)1
0L114348 BOLT (3/8-16X2.5-IN)4
7J402649 ELBOW2
5T437550 HOSE AS2
133141251 CONTROL GP-ENGINE MONITORING1
125382752 HARNESS AS1
7K919753 ELBOW2
6K919454 ELBOW1
102159455 BRACKET AS1
0S157156 BOLT (3/8-16X1.75-IN)6
136590857 TUBE AS1
2P131458 CONNECTOR1
030818859 CONNECTOR1
136591060 TUBE AS1
9W053261 SENSOR GP-TEMPERATURE2
7D723362 CLIP (LOOP)2
0S159463 BOLT (3/8-16X1-IN)2
0L207264 CLIP2
9M413665 SPACER (0.438X0.75X0.5-IN THK)2
100783466 PLATE AS2
1F0750NUT-WELD (3/8-16-THD)2
125383267 HARNESS AS (AIR RESTRICTION LEFT)1
125383368 HARNESS AS (AIR RESTRICTION RIGHT)1
125382669 HARNESS AS (GAS SHUTOFF VALVE)1
125382870 HARNESS AS1
6B507271 ADAPTER2
7D409272 CLIP1
4S196273 CLIP (LOOP)1
125381474 HARNESS AS1
3V243175 WASHER (10.2X16X2-MM THK)4
2N347876 SCREW-MACHINE (10-24X0.375-IN)4
128632577 BUSHING1
125786178 SEAL3
130941879 BRACKET1
5P007680 BOLT-12 POINT HEAD (3/8-16X1.5-IN)4
030794681 ELBOW2
3E918982 SENSOR GP-PRESSURE2
5P053783 WASHER-HARD (7.2X14.5X2-MM THK)8
2A554684 BOLT (1/4-20X1.375-IN)8
9X677285 STRAP-CABLE15
3V330886 WASHER-HARD (10.2X20.5X2.5-MM THK)8
9X677287 STRAP-CABLE1
6V504888 SEAL-O-RING2
6V504989 SEAL-O-RING3
8L278690 SEAL-O-RING3
4P758191 CLIP (LADDER)1
4J944892 LUG8
068994193 WIRE-TIE4
030819594 CONNECTOR1
6V458995 SEAL-O-RING1
113203896 TUBE AS1
4S639997 CONNECTOR1
7J874498 WASHER (0.781X0.125X0.075-IN THK)1
9M735799 COUPLING AS1
3N1400100 SWITCH AS-PRESSURE (PRELUBE OIL PRESSURE)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
2L8075101 TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW)2
9Y1925102 BOX AS1
0S1594103 BOLT (3/8-16X1-IN)8
4S1962104 CLIP (LOOP)2
0S1591105 BOLT (3/8-16X1.5-IN)1
6K8179106 CLIP2
1257861107 SEAL2
1253810108 HARNESS AS1
7D1553109 CLIP1
9S8752110 NUT-FULL (3/8-16-THD)9
6V9601111 ADAPTER1
5P9297112 CLIP (LOOP)2
1253819113 HARNESS AS1
1253822114 HARNESS AS (AIR PRELUBRICATION SOLENOID)1
1253821115 HARNESS AS (START AIR SOLENOID)1
8S4626116 SPLICE-WIRE4
1253843117 HARNESS AS (COMBUSTION BUFFER)2
1253844118 HARNESS AS (COMBUSTION BUFFER)2
1253845119 HARNESS AS (COMBUSTION BUFFER)1
0S1571120 BOLT (3/8-16X1.75-IN)4
1S0994121 CLIP (LOOP)1
1253846122 HARNESS AS1
1253877123 BOX GP-JUNCTION1
2N3162124 SCREW-MACHINE (10-24X1.25-IN)4
1296687125 BRACKET1
1253842126 HARNESS AS (COMBUSTION BUFFER)2
1253876127 HARNESS AS1
1A2029128 BOLT (3/8-16X1.125-IN)1
1253860129 HARNESS AS1
1253862130 HARNESS AS1
9X6772131 STRAP-CABLE2
3V3308132 WASHER-HARD (10.2X20.5X2.5-MM THK)23
4P8134133 CLIP (LADDER)13
9X6772134 STRAP-CABLE13
6V8647135 CONNECTOR1
6V5048136 SEAL-O-RING1
6V5049137 SEAL-O-RING1
5P8245138 WASHER-HARD (13.5X25.5X3-MM THK)5
5N2840139 CLIP1
4D8948140 CLIP2
1253865141 HARNESS AS (COMBUSTION BUFFER)1
1310719142 BRACKET1
0S1587143 BOLT (1/2-13X1.75-IN)1
0S1595144 BOLT (1/2-13X1.25-IN)1
1F7958145 NUT-FULL (1/2-13-THD)1
5K3294146 CLIP1
2W8739147 BRACKET1
9X5272148 SENSOR GP-PRESSURE1
1253808149 HARNESS AS1
1253809150 HARNESS AS1
1253825151 HARNESS AS1
0L2070152 BOLT (3/8-16X2.25-IN)2
0S1594153 BOLT (3/8-16X1-IN)12
4S1962154 CLIP (LOOP)12
1253824155 HARNESS AS1
0352017156 SCREW-BUTTON HEAD (3/8-16X1-IN)1
3V2431157 WASHER (10.2X16X2-MM THK)2
1257861158 SEAL5
1253823159 HARNESS AS1
9S8752160 NUT-FULL (3/8-16-THD)8
5P9297161 CLIP (LOOP)2
0S1571162 BOLT (3/8-16X1.75-IN)4
8M2770163 CLIP (LOOP)3
6K8179164 CLIP1
1253846165 HARNESS AS1
2N3162166 SCREW-MACHINE (10-24X1.25-IN)8
1296687167 BRACKET1
0919035168 SPACER (11X25X20-MM THK)2
3B1915169 BOLT (3/8-16X1.375-IN)12
5P7854170 CLIP (LOOP)5
4H1225171 WASHER (11X22X6-MM THK)12
1A2029172 BOLT (3/8-16X1.125-IN)2
1253852173 HARNESS AS1
1253861174 HARNESS AS1
1253859175 HARNESS AS1
1253812176 HARNESS AS1
1297636177 BOX GP-JUNCTION1
3E8689178 SENSOR GP-PRESSURE1
5P0076179 BOLT-12 POINT HEAD (3/8-16X1.5-IN)2
0307946180 ELBOW1
3J7354181 SEAL-O-RING2
7C9897182 HOSE AS1
3J7352183 CONNECTOR1
1253857184 HARNESS AS1
1309417185 BRACKET1
1253855186 HARNESS AS1
1257859187 BOX GP-JUNCTION1
1253858188 HARNESS AS1
1253853189 HARNESS AS1
0S0509190 BOLT (3/8-16X0.75-IN)1
1257860191 BRACKET AS1
1253839192 HARNESS AS (COMBUSTION BUFFER)2
1253840193 HARNESS AS (COMBUSTION BUFFER)2
1253841194 HARNESS AS (COMBUSTION BUFFER)1
1253863195 HARNESS AS (COMBUSTION BUFFER)1
9X6772196 STRAP-CABLE13
3V3308197 WASHER-HARD (10.2X20.5X2.5-MM THK)41
4P8134198 CLIP (LADDER)12
9X6772199 STRAP-CABLE16
5P8245200 WASHER-HARD (13.5X25.5X3-MM THK)5
4P7429201 CLIP (LADDER)3
4D8948202 CLIP2
1310719203 BRACKET1
0S1587204 BOLT (1/2-13X1.75-IN)1
0S1595205 BOLT (1/2-13X1.25-IN)1
1F7958206 NUT-FULL (1/2-13-THD)1
5K3294207 CLIP1
2W8739208 BRACKET1
3S8665209 CLIP (LOOP)1
3S8664210 CLIP4
