219-9930 BYPASS GP-EXHAUST (CHG -01 THRU -04)Type 2

Group No: 219-9930

Part Number	Part Name	Qty
1S3584	2 NUT-FULL (3/8-24 LH-THD)	2
2W0439	3 GASKET	1
3H6630	4 BOLT (3/8-16X3.25-IN)	6
3S2713	5 NUT-FULL (3/8-24-THD)	2
4F2753	6 LOCKNUT	1
4P0391	7 ROD	1
4P0394	8 LEVER	3
5H2532	9 KEY-WOODRUFF	3
5L3291	10 BEARING AS-BALL (SELF-ALIGNING)	2
5P2755	11 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN)	4
5P9960	12 BOLT (1/4-20X0.75-IN)	2
6I2527	13 ELBOW-EXHAUST	1
6V1943	14 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN)	2
6V6753	15 BOLT-HIGH TEMPERATURE (3/8-16X1.375-IN)	1
7C8363	16 GASKET	1
7E0701	17 GASKET	2
7E2946	18 COVER	1
7L6443	19 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN)	12
7W9115	20 ADAPTER-EXHAUST	1
7W9191	21 GASKET	1
8C7315	22 ROD END	1
8C7321	23 ROD END	1
8H3390	24 NUT-FULL (1-1/2-12-THD)	1
8M2295	25 BOLT (3/8-16X1.625-IN)	2
0399895	26 ROD	1
1021694	27 PLATE	1
1023457	28 COVER	1
1026309	29 WASHER-THRUST	1
1026311	30 STOP	1
1108314	31 WASHER (10.3X18.3X2.66-MM THK)	4
1184736	32 SHAFT-WASTEGATE	1
1195927	33 SHAFT	1
1195930	34 HOUSING AS	1
1195929	BUSHING	2
1195931	35 SPACER	1
1338501	36 COVER AS	1
1419885	37 BRACKET AS	1
1763583	38 GUARD	2
1763587	39 CLEVIS	1
1937879	40 BOOT	1
2118175	41 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC)	1
2224718	42 BELLOWS AS	1
1653931	43 BOLT (3/8-16X1.75-IN)	6
0S1588	45 BOLT (3/8-16X1.25-IN)	4
0S1590	46 BOLT (3/8-16X2-IN)	1
1653929	47 BOLT (3/8-16X1.5-IN)	4
0S1595	48 BOLT (1/2-13X1.25-IN)	18
1190746	49 PLUG-PIPE	2
2253769	51 ROD END	1
2253770	52 ROD END	1
2N2766	53 LOCKNUT (3/8-16-THD)	22
3V3308	54 WASHER-HARD (10.2X20.5X2.5-MM THK)	26
5P8245	55 WASHER-HARD (13.5X25.5X3-MM THK)	6
6V8675	56 BOLT (M12X1.75X35-MM)	6
8C8491	57 WASHER-HARD (10.2X22X3-MM THK)	24
8M9024	58 WASHER-HARD (10.2X22.5X5-MM THK)	3
9S8752	59 NUT-FULL (3/8-16-THD)	11
3512247	61 BOLT (3/8-16X1.5-IN)	4
