Assembly
100%

259-8435 TURBOCHARGER GP (CHG -00 THRU -03)Type 1

Group No: 259-8435
Part NumberPart NameQty
17636112 CLAMP-BAND1
17817903 CLAMP3
17817914 BOLT (M12X1.75X35-MM)18
17817975 STUD (M12X1.75X65-MM)12
17817986 NUT (M12X1.75-THD)24
20761097 CLIP4
20761108 WASHER (12.5X21X2.7-MM THK)12
20761119 STUD (M12X1.75X35-MM)12
230093310 HOUSING-COMPRESSOR1
230093611 INSERT (TURBINE)1
262711612 HOUSING-BEARING1
262711713 HOUSING AS-TURBINE1
273210514 CARTRIDGE GP-TURBOCHARGER1
230093718 DIFFUSER1
364368819 RING-NOZZLE1
230093920 INSERT1
178179921 BOLT (M12X1.75X25-MM)5
178180022 WASHER (14X29X3-MM THK)7
178180123 BOLT (M12X1.75X42.5-MM)2
2939480SENSOR AS-SPEED1
2076106KIT-TURBOCHARGER SEAL1
1763609KIT-SEAL (BEARING)1
1763610KIT-BEARING (TURBOCHARGER)1
