System And Components
259-8435 TURBOCHARGER GP (CHG -04)Type 2
Group No: 259-8435
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1781801 | 1 BOLT (M12X1.75X42.5-MM) | 2 | |
| 1763611 | 2 CLAMP-BAND | 1 | |
| 1781790 | 3 CLAMP | 3 | |
| 1781791 | 4 BOLT (M12X1.75X35-MM) | 18 | |
| 1781797 | 5 STUD (M12X1.75X65-MM) | 12 | |
| 1781798 | 6 NUT (M12X1.75-THD) | 24 | |
| 2076109 | 7 CLIP | 4 | |
| 2076110 | 8 WASHER (12.5X21X2.7-MM THK) | 12 | |
| 2076111 | 9 STUD (M12X1.75X35-MM) | 12 | |
| 2300933 | 10 HOUSING-COMPRESSOR | 1 | |
| 2300936 | 11 INSERT (TURBINE) | 1 | |
| 2627117 | 13 HOUSING AS-TURBINE (TURBINE) | 1 | |
| 2732105 | 14 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 2300937 | 18 DIFFUSER | 1 | |
| 3643688 | 19 RING-NOZZLE | 1 | |
| 2300939 | 20 INSERT | 1 | |
| 1781799 | 21 BOLT (M12X1.75X25-MM) | 5 | |
| 1781800 | 22 WASHER (14X29X3-MM THK) | 7 | |
| 3307835 | 24 SHIELD AS | 1 | |
| 2300946 | 25 RING | 1 | |
| 2939480 | SENSOR AS-SPEED | 1 | |
| 2076106 | KIT-TURBOCHARGER SEAL | 1 | |
| 1763609 | KIT-SEAL (BEARING)(TURBOCHARGER) | 1 | |
| 1763610 | KIT-BEARING (TURBOCHARGER) | 1 |
