System And Components
219-9933 LINES GP-GAS (CHG -00 THRU -06)
Group No: 219-9933
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C6868 | 1 CONNECTOR | 16 | |
| 1054046 | 2 TUBE AS | 8 | |
| 1182735 | 3 VALVE-NEEDLE | 8 | |
| 1317752 | 4 ADAPTER AS | 1 | |
| 2105638 | 5 TUBE AS | 8 | |
| 2105639 | 6 TUBE AS | 8 | |
| 2199954 | 7 TUBE AS | 1 | |
| 2659703 | 8 BRACKET AS | 1 | |
| 0L1143 | 9 BOLT (3/8-16X2.5-IN) | 1 | |
| 1653931 | 10 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 32 | |
| 0S1590 | 12 BOLT (3/8-16X2-IN) | 6 | |
| 1653929 | 13 BOLT (3/8-16X1.5-IN) | 4 | |
| 1249633 | 14 CLIP (SLOT) | 8 | |
| 3V3308 | 15 WASHER-HARD (10.2X20.5X2.5-MM THK) | 40 | |
| 9L9132 | 16 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 5P8211 | 17 SEAL-O-RING | 8 | |
| 6J2244 | 18 SEAL-O-RING | 16 | |
| 6V5039 | 19 CLIP (SLOT) | 4 | |
| 6V5040 | 20 CLIP (TAB) | 4 | |
| 2147568 | 21 SEAL-O-RING | 17 | |
| 6V8002 | 22 SEAL-O-RING | 1 | |
| 6V8636 | 23 CONNECTOR | 8 | |
| 8L2779 | 24 SEAL-O-RING | 32 | |
| 8L2786 | 25 SEAL-O-RING | 1 | |
| 8M7145 | 26 WASHER (10.2X28.5X5-MM THK) | 8 | |
| 8M9024 | 27 WASHER-HARD (10.2X22.5X5-MM THK) | 6 | |
| 8T0075 | 28 CONNECTOR | 8 | |
| 9D6196 | 29 CLIP (SLOT) | 4 | |
| 9D6197 | 30 CLIP (TAB) | 4 | |
| 9S4185 | 31 PLUG (3/4-16-THD) | 1 | |
| 9S4191 | 32 PLUG (9/16-18-THD) | 1 | |
| 9S8752 | 33 NUT-FULL (3/8-16-THD) | 11 |
